MCP6P3
47
仕様
SATAコネクタ x4 各コネクタは1つのSATAデバイスをサポートします
フロントパネルコネクタ x1 フロントパネル機能をサポートします
フロントオーディオコネクタ x1 フロントパネルオーディオ機能をサポートします
S/PDIFアウトコネクタ x1 デジタルオーディオアウト機能をサポートします
CPUファンヘッダ x1 CPUファン電源装置(スマートファン機能を搭載)
システムファンヘッダ x1 システムファン電源装置
CMOSクリアヘッダ x1
USBコネクタ x3
各コネクタは2つのフロントパネルUSBポートをサポートし
ます
電源コネクタ(24ピン) x1
電源コネクタ(4ピン) x1
背面パネル
I/O
PS/2キーボード x1
PS/2マウス x1
VGAポート x1
シリアルポート x1
LANポート x1
USBポート x4
オーディオジャック x3
ボードサイズ 190 mm (幅) X 244 mm (高さ)
特殊機能 RAID 0 / 1 / 0+1 / 5 のサポート
OSサポート Windows XP / Vista / 7
BIOSTARは事前のサポートなしにOSサポートを追加または
削除する権利を留保します。
2009/11/20
