FT-1205A

Switch 1

On 2-Port Redundant (Fiber)

Off 3-Port Switch (default)

Switch 2

On LBR ON

Off LBR OFF (default)

2-Port Redundant (FT-1205A)

When Fiber Redundancy is enabled, Fiber Port-1 (1) and Fiber

Port-2 (2) are congured as either forwarding or disabled. At

any given time, one port will be disabled and one port will be

forwarding.

3-Port Switch

When Fiber Redundancy is disabled, all ports (Port-1, Port-2 and

Port-3) act as normal bridging ports.

Note

FT-1105A / FT-1205A supports OAM/TS-1000

protocol for remote status monitor. To enable the

OAM support function, set the DIP Switch 2 “On”.
