LED Color Function
LNK/
ACT
Green
Lit: Indicate that the port is link up.
Blink:
Indicate that the converter is
actively sending or receiving data
over that port.
Off: Indicate that the port is link down.
FDX/
COL
Green
Lit:
Indicate that the connection made
through the corresponding port is
running in Full-Duplex mode.
Off:
Indicate that the connection made
through the corresponding port is
running in Half-Duplex mode.
FT-1205A -100Base-FX SFP Port
LED Color Function
1
2
Green
Lit: Indicate that the port is link up.
Blink:
Indicate that the converter is
actively sending or receiving data
over that port.
Off: Indicate that the port is link down.
