21
Chapter 10 PRODUCT SPECIFICATION
Model FT-1105A FT-1205A
Ports
Copper 2 x 10/100Base-TX port 1 x 10/100Base-TX port
Fiber 1 x 100Base-FX port 2 x 100Base-FX port
Optic Interface SFP SFP
Redundant Link
Port 2 (Primary)
Port 3 (Backup)
Port 1 (Primary)
Port 2 (Backup)
Cable
Twisted-
pair
10Base-T : 2-Pair UTP Cat. 3,4,5, up to 100 m
100Base-TX : 2-Pair UTP Cat. 5, 5e up to 100 m
Fiber-optic
cable
● 50/125μm or 62.5/125μm multi-mode ber cable,
up to 2km.
● 9/125μm single-mode cable, provide long distance
for 20/40/60km or longer (very on SFP module)
Speed
Twisted-
pair
10/20Mbps for Half/Full-Duplex
100/200Mbps for Half/Full-Duplex
Fiber-optic 200Mbps for Full-Duplex
LED indicator
System: One Power LED,
TP Port:
● One Speed
(On: 100Mbps;
Off: non-100Mbps),
● One LNK/ACT
Fiber Port:
● One Link/Act,
● One FDX/Col
System: One Power LED,
TP Port :
● One Speed
(On: 100Mbps;
Off: non-10Mbps),
● One LNK/ACT
Fiber Port:
● One Link/Act
DIP Switches
DIP 1: On 3-Port Switch Mode
Off 2-Port Redundant
DIP 2: On Loop Back Reply Enable
Off Loop Back Reply Disable
Standards
IEEE 802.3, 10Base-T
IEEE 802.3u, 100Base-TX, 100Base-FX
IEEE 802.3x Flow Control
