Note

It recommends using PLANET MFB-FX series

100Base-FX SFP on the converter. If you insert

a SFP transceiver that is not supported, the

converter will not recognize it.

Step 4: Connect the ber cable. Attach the duplex LC connector

on the network cable into the SFP transceiver.

Step 5: Attach ber cable from the FT-1105A/FT-1205A to the

ber network. TX, RX must be paired at both ends.

Step 6: Connect the 5VDC power adapter to the FT-1105A/FT-

1205A and verify that the Power LED lights up.

Step 7: Turn on the power of the device/station; the PWR LEDs

should light when all cables are attached.

Note

Please refer to APPENDIX-A for detailed wiring

information of the FT-1105A/FT-1205A.

To prevent from optic acceptor malfunction, check

the both wires / transmitter before power on the

converter.

6.2 Chassis Installation and Rack Mounting

To install the media converter in a 10-inch or 19-inch with

standard rack, follow the instructions described below.

Step 1: Place your FT-1105A/FT-1205A on a hard at surface,

with the front panel positioned towards your front side.
