8
Chapter 2 PRODUCT FEATURES
Standard
• Complies with IEEE 802.3, IEEE 802.3u 10/100Base-TX,
100Base-FX
• IEEE 802.3x Full-Duplex Flow-Control, Back-Pressure in Half-
Duplex eliminate packets loss
Interface
• FT-1105A: Dual 10/100Base-TX Copper, One 100Base-FX SFP
Fiber optic
●
FT-1205A: Dual 100Base-FX SFP Fiber optic, One
10/100Base-TX Copper
● Auto-Negotiation for 10/100Base-TX Half-Duplex or Full-
Duplex
● Supports Auto MDI/MDI-X function
● Supports Maximum frame size up to 2046Kbytes.
Redundancy
● Link status auto detect and redundant on Dual ports with
same connector type.
● Only Primary-Port is active at a time, the Backup-Port is
blocked.
● While Primary-Port link fail occur, the trafc swap to Backup-
Port automatically.
● Once the Primary-Port status back to link up, the trafc swap
from Backup-Port to Primary-Port.
● Hardware redundant swap less than 10 ms.
Mechanical
● External 5V/2A DC power supply
● LED indicators for easy network diagnose
