Planet FT-1205A [18/24] Chapter 8 loop back reply
![Planet FT-1205A [18/24] Chapter 8 loop back reply](/views2/1071199/page18/bg12.png)
18
Chapter 8 Loop Back Reply
The FT-1105A / FT-1205A supports auto loop back reply while
receive loop back test packets on ber port. Enable this function
to tell the converter to reply ber signals request from Web
Smart media converter, such as PLANET FT-90x. You can use
this to check whether the converter can communicate with
partner converter. Please refer to the following gure.
Note
For FT-1105A only, while enable the Loop Back
Reply function, the Port-2 (TP) must be link up.
