8. LED indication
n System
LED Color Function
PWR Green Lit: Indicate the device is powered.
n 10/100Base-TX Port
LED Color Function
LNK/ACT Green
Blink
Indicate that the Media Converter
is actively sending or receiving data
over that port.
Lit Indicate that the port is link up.
Off Indicate that the port is link down.
PoE in
Use
Green
Lit
Indicate that the port is providing
48VDC to remote powered device.
Off
Indicate that the port is not providing
48VDC to remote powered device.
n 100Base-FX SC Port
LED Color Function
LNK/ACT Green
Blink
Indicate that the Media Converter
is actively sending or receiving data
over that port.
Lit Indicate that the port is link up.
Off Indicate that the port is link down.
Note
Fiber-optic Partner should be set to the correct
mode according to this FDX indicator for optimal
network performance.
