Planet FTP-802S15 [19/22] Appendix a

APPENDIX A

A.1 Device‘s RJ-45 Pin Assignments

n 10/100Mbps, 10/100Base-TX

Contact MDI MDI-X

1 1 (TX +) 3

2 2 (TX -) 6

3 3 (RX +) 1

6 6 (RX -) 2

4, 5, 7, 8 Not used Not used

Implicit implementation of the crossover function within a

twisted-pair cable, or at a wiring panel, while not expressly

forbidden, is beyond the scope of this standard.

A.2 RJ-45 cable pin assignment

There are 8 wires on a standard UTP/STP cable and each wire is

color-coded. The following shows the pin allocation and color of

straight cable and crossover cable connection:
