Planet FTP-802S15 [17/22] Cable connection parameter

9. Cable Connection Parameter

The limitations are as below:

Duplex Connection Limitation (max.)

Twisted Pair

Half / Full

Node to Node

Node to Switch/Hub

100 meters

Multi-Mode Converters

MM Half

Node to Node

Node to Switch

412 meters

MM Full

Node to Node

Node to Switch

FTP-802: 2 kilometers

Single-Mode Converters

SM Full

Node to Node

Node to Switch

FTP-802S15: 15 kilometers
