17
10. FTP-80X Technical Specications
The FTP-80X comes with the following standard features:
Standard: IEEE 802.3u, 10/100Base-TX ,100Base-FX
IEE
E 802.3af Power over Ethernet
Connectors:
n One RJ-45 (Auto-MDI/MDI-X) Twisted Pair, EIA568 with PoE
n One Fiber-optic, 1310nm wavelength, connector-type vary
with model
Data Transfer Rate: 10/100Mbps (TP), 100Mbps (FX)
Duplex mode support: Full or half-duplex mode by Auto-
Negotiation (TP)
LED indicators: PWR, FX LNK/ACT, TX LNK/ACT, PoE in Use
PoE Power Output: 48V DC, Max. 15.4 watts, 350mA
Power Pin Assignment: 1/2(+), 3/6(-) / End-Span
Power Supply: 48V DC, 0.4A, external AC-DC adapter
Ambient Temperature: 0° to 50°C (operating)
Humidity: 5% to 90% (non-condensing)
Dimension: 26 x 70 x 97mm (H x W x D)
Cable:
n UTP: Cat 5 UTP cable
n F
iber: MM: 50/125 µm or 62.5/125 µm optic ber
n Fiber: SM: 9/125 µm optic ber
Co
nnecting to Router, Bridge, or Switch, Hub, please refer to the
device’s Technical Manual.
