Planet FTP-802S15 [20/22] A fiber optical cable connection parameter

Figure A-1: Straight-Through and Crossover Cable

Please make sure your connected cables are with same pin

assignment and color as above picture before deploying the

cables into your network.

A.3 Fiber Optical Cable Connection Parameter

The wiring details are as below:

n Fiber Optical patch Cables:

Standard Fiber Type Cable Specication

100Base-FX

(1310nm)

Multi-mode 50/125μm or 62.5/125μm

100Base-FX

(1310nm)

Single-mode 9/125μm
