Planet WAP-4033 [13/37] Parameter description

Parameter Description

Mode Shows the current operation mode.

Band

2.4GHz (B): It forces the WAP-4033 to operate in 802.11b only.

2.4GHz (G): It forces the WAP-4033 to operate in 802.11g only.

2.4GHz (B+G): It allows the WAP-4033 to operate in 802.11b and 802.11g

simultaneously.

ESSID The ESSID (up to 32 printable ASCII characters) is the unique name identified in a

WLAN. The ID prevents the unintentional merging of two co-located WLANs.

Please make sure that the ESSID of all stations in the same WLAN network are

identical. The default ESSID is “default”.

Channel Number Select the appropriate channel from the list provided to correspond with your

network settings. Channels differ from country to country.

Channel 1-11 (North America)

Channel 1-14 (Japan)

Channel 1-13 (Europe)

Associated Clients

You may press “Show Active Clients” button to check the connected client

information. After the button pressed, you will see the dialog box as below.

You may press “Refresh” to get the new client table or “Close” to close this dialog

box.

After configuration complete, please click “Apply” button to save the configuration. Then you will

see a screen below to prompt you the settings are save successfully. If you press “Continue”,

you can proceed to configure other settings. However, the new configurations are not take

effect at this time. You must click “Apply”, and then the WAP-4033 will restart with new

configuration. You may check the LED status to make sure WAP-4033 finishes the restart.
