Planet WAP-4033 [17/37] Ap bridge point to multipoint mode

2.4GHz (G): It allows to select the transmit rate up to 54Mbps.

2.4GHz (B+G): It allows selecting the 802.11b and 802.11g data rates.

Channel Number Select the appropriate channel from the list provided to correspond with your

network settings. Channels differ from country to country.

Channel 1-11 (North America)

Channel 1-14 (Japan)

Channel 1-13 (Europe)

MAC Address 1

Keep default setting: WAP-4033 will use it’s own MAC address to access the

wireless LAN.

Press “MAC Clone” button: It will use PC’s MAC address to access the

wireless LAN.

Set Security If you want to enable security to protect your wireless bridge connection, please

press “Set Security” button and refer to section 3.2.8 “Security setting for bridge

mode” to configure the detail settings.

After configuration complete, please click “Apply” button to save the configuration. Then you will

see a screen to prompt you the settings are save successfully. You may press “Continue” for

configure other settings or “Apply” to restart WAP-4033 with new configuration.

3.2.5 AP Bridge - Point to Multipoint Mode

This function allows WAP-4033 to bridge more than 2 wired Ethernet networks together by

wireless connection.
