K8T80-A7
3
Back Panel I/O Connectors
4 USB 2.0 ports.
1 serial port.
1 parallel port.
1 RJ-45 LAN jack.
1 PS/2 Mouse & Keyboard port.
1 vertical audio port including 1 line-in connector, 1 Line out
connector, and 1 MIC in connector.
PS/2
Keyboard
PS / 2
Mouse
Parallel
LAN
USB x2
Line In/
Surround
Line Out
M ic In 1/
Base /Center
USB x2
JCOM2
BB.. BBIIOOSS && SSooffttwwaarree
BIOS
Award legal BIOS.
Supports APM1.2, ACPI, and USB functions.
Software
Supports 9
th
Touch
TM
, Flasher
TM
, WinFlasher
TM
, and
Warpspeeder
TM
.
Offers the highest performance for Windows 98SE, Windows NT,
Windows 2000, Windows ME, Windows XP, Linux Fedora, and
UNIX series.
1.2 PACKAGE LIST
FDD cable x1
HDD cable x1
User’s Manual x1
Fully Setup Driver CD x1
Rear I/O panel for ATX case x1
USB 2.0 cable x1 (optional)
Serial ATA cable x2 (optional)
S/PDIF out cable x1 (optional)
