Biostar K8T80-A7 [6/66] K8t80 a7

K8T80-A7

1.3 LAYOUT

JKBMS1

JU SB1

JA UD IO 1

JU SBLAN 1

JPRN T1

JCOM2

PCI1

GP1

PCI5

PCI4

PCI3

PCI2

C NR1

CPU1

BIOS

DIMM1

DIMM2

BAT1

ID E1 FDD1

ID E2

K8T800 Pro

VT8237R

J KBV1

JATXPWR2

JATXPWR1

JUSBV1

JAUDIO 2

JCDI N1

JSPDIF_OUT1

J USB4

10 2

JUSB3

JU SBV2

JSATA2

JSATA1

JCMOS1

JCI1

JCFAN1

JSF AN 1

Codec

JPANEL1

224

LAN

Super I/O

Note: ■ represents the 1

pin.
