GeForce 6100-M7
16
Row precharge Time (tRP)
This field specifies the Row precharge Time. Precharge to Active or
Auto-Refresh of the same bank. Typically 20-24 Nsec.
The Choices: 2T (default).
User Config Mode
The Choices: Auto (default), Manual.
1T/2T Memory Timing
The Choices: 2T (default).
MIRR mapping mode
The Choices: Continuous (default), Discrete.
CPU Spread Spectrum
The Cho ices : Disabled (default), Center, Down.
PCIE Spread Spectrum
This item allows you to disable \ enable the SATA spread spectrum function.
The Cho ices : Disabled (default), Enable.
SATA Spread Spectrum
This item allows you to disable \ enable the SATA spread spectrum function.
The Cho ices: Disabled (default), Enabled.
HT Spread Spectrum
The Cho ices : Disabled (default), Center, Down.
SSE/SSE2 Instructions
The Choices: Enabled (default), Disabled.
System BIOS Cacheable
Selecting the “Disabled ” option allows caching of the system BIOS ROM at
F0000h-FFFFFh which can improve system performance. However, any
programs writing to this area of memory will cause conflicts and result in
system errors.
The Cho ices: Disabled (default), Enabled.
