PLANET Mesh Network Manager Guide

3) WAN Downlink Speed

• Define the download speed of the WAN interface

• Data type: Integer, in the range of 5 and 100 Mbps

4) User Uplink Speed

• Define the user default upload speed.

• Data type: Integer, in the range of 32 and 65535 kbps

5) User Downlink Speed

• Define the user default download speed

• Data type: Integer, in the range of 32 and 65535 kbps

Parameters (Traffic Shaping Table)

1) Protocol

• The protocol to use.

• Available choice: UDP, TCP and Both

2) Port

• The port number

• Data type: Integer, in the range of 1 and 65535

3) Min Size

• The minimum size of the data packet

• Data type: Integer, in the range of 1 and 65535

4) Max Size

• The maximum size of the data packet

• Data type: Integer. in the range of 1 and 65535

5) Priority

• The priority to be assigned to the rule

• Available choice: Background, Video, Voice and Best Effort

6) Comment

• An optional comment regarding the table entry

• Data type: Display String

7) Status

• The status of the table entry, either active or inactive
