Ariston STYLE 7OFH 1039 P IX [5/28] Start up and use

! The first time you use your appliance, heat the empty

oven with its door closed at its maximum temperature

for at least half an hour. Ensure that the room is well

ventilated before switching the oven off and opening

the oven door. The appliance may emit a slightly

unpleasant odour caused by protective substances

used during the manufacturing process burning away.

! The “Control panel lock” and “DEMO mode” can be

activated/deactivated even when the control panel is

switched off.

Control panel lock

To lock the oven controls, press the and

buttons simultaneously. A buzzer will sound and the

TEMPERATURE display shows "Loc".

Press again to unlock the controls. The "STOP" button

is always active.

Demo mode

The oven can operate in the DEMO mode: all heating

elements are deactivated, and the controls remain

operative.

To activate the DEMO mode, press the "+",

, and

"START" buttons simultaneously. A buzzer will

sound and the TIME display shows "DEMO".

To activate the DEMO mode, press the "+" and "START"

buttons simultaneously. A buzzer will sound and the

"DEMO" message disappears from the display.

Setting the clock and timer

After connection to the power supply network or after a

blackout, the

button and the digits on the TIME

display will flash.

To set the time:

1. Press buttons "+" and "-"; press and hold to scroll

the numbers quicker and make setting easier.

2. Once the exact time is reached, wait 10 seconds for

the selection to be memorized, or press the

button

again to fix the setting.

To make any necessary changes, switch off the control

panel by pressing the

; button, then press the

button and follow the steps indicated.

When the set time has elapsed, the timer emits a

buzzer that will automatically stop after 6 seconds or

when any active icon on the control panel is pressed.

To set the timer, press the

button and follow the

procedure used to set the clock. The

button

switched on indicates that the timer has been activated.

! The timer does not switch the oven on or off.

Starting the oven

1. Switch the control panel on by pressing the

button.

2. Press the button corresponding to the desired

cooking mode. The TEMPERATURE display shows the

temperature of the cooking mode; the TIME display

shows the current time.

3. Press the "START" button to begin cooking.

4. The oven will begin its preheating phase, the current

temperature indicators will light up as the temperature

rises. The temperature may be adjusted by pressing

the "+" and "-" buttons.

5. When preheating is finished, a buzzer will sound

and all current temperature indicators will be turned on:

the food can then be placed in the oven.

6. During cooking it is always possible to:

- adjust the temperature by pressing the "+" and "-"

buttons;

- set the duration of a cooking mode (see Cooking

Modes);

- interrupt cooking by pressing the "STOP" button.

7. In case of a blackout, an automatic system will

reactivate the cooking mode from where it was

interrupted, provided the oven temperature has not

dropped below a certain level. Programmed cooking

modes which have not started will not be restored and

must be reprogrammed.

! There is no preheating stage for the BARBECUE

mode.

! Never put objects directly on the bottom of the oven;

this will avoid the enamel coating being damaged.

! Always place cookware on the rack(s) provided.

Cooling ventilation

In order to cool down the external temperature of the

oven, a cooling fan generates a stream of air which

escapes between the oven control panel and the oven

door. At the beginning of the FAST CLEAN mode, the

cooling fan operates at low speed.

! Once the cooking has been completed, the cooling

fan continues to operate until the oven has cooled

down sufficiently.

Oven light

When the oven is not in operation, the lamp can be

switched on at any time by opening the oven door.

Start-up and use
