FXLQ-MA
FXNQ-MA
p. 48
COMFORT
9
Ideal for installation beneath a window
9 Compact dimensions (only 222mm deep and 600mm high)
9 All models are available with remote control
FILTER
9 Long life filter fitted as standard
FLEXIBLE INSTALLATION & EASY MAINTENANCE
9 Running the pipes from connections at the back,
enables the unit to be wall mounted
9 On site connection during installation is easier
9 The fibreless discharge grille prevents condensation and staining
COMFORT
9 Ideal for perimeter air conditioning
9 Ideal for installation below a window
9 All models are available with remote control
FILTER
9 Long life filter fitted as standard
FLEXIBLE INSTALLATION
9 On site connection during installation is easier
9 The connecting port faces downward, eliminating the need to attach
auxiliary piping
Wall mounted Floor standing
Connecting
port
Refrigerant
piping
20-25-32-40-50-63
20-25-32-40-50-63
1602UKEPCEN07-200-artwork.indd 481602UKEPCEN07-200-artwork.indd 48 1/8/07 07:16:321/8/07 07:16:32
