BRC1D52
p. 67
Wired remote control
9 Limit operation (min/max): room temperature is controlled within
adjustable upper and lower limits. Limit operation can be activated
manually or by schedule timer
9 Real time clock: indicates real time and day
9 Schedule timer:
• It is possible to programme a weekly schedule timer
• It is possible to programme the remote control for each day of the
week.
Five day actions can be set as follows:
- Set point: unit is switched ON and normal operation is maintained
- OFF: unit is switched OFF
- Limits: unit is switched ON and min/max control (cf. limit operation for
more details)
9 Home leave (frost protection): during occupants’ absence, the indoor
temperature can be maintained at a certain level. This function can also
switch the unit ON/OFF
9 Different levels of disabled buttons can be selected as follows:
• Level 1: all buttons are accessible
• Level 2: all buttons are disabled except for: ON/OFF, set temperature
up/down, fan speed, cooling/heating mode, enable/disable schedule
timer, air flow direction adjustment button
• Level 3: all buttons are disabled except for: ON/OFF, set temperature
up/down, fan speed
9 User friendly HRV function, thanks to the introduction of a button for
ventilation mode and fan speed
9 Constantly monitoring of the system for malfunctions in a total of 80
components
9 Immediate display of fault location and condition
9 Reduction of maintenance time and costs
Operation buttons: ON/OFF, timer mode start/stop, timer on/off, programmed
time, temperature setting, air flow direction adjustment, operating mode
selection, fan speed control, filter sign reset, inspection test/operation
Display: Operating mode, Heat Recovery Ventilation (HRV) in operation,
cool/heat changeover control, centralised control indication, group control
indication, set temperature, air flow direction, programmed time, inspection/
test operation, fan speed, clean air filter, defrost/hot start, malfunction
