DCS302C51
Centralised remote control
Providing individual control of 64 groups (zones) of indoor units
9 A maximum of 64 groups (128 indoor units, max. 10 outdoor units) can be
controlled
9 A maximum of 128 groups (128 indoor units, max. 10 outdoor units) can be
controlled via 2 centralised remote controls in separate locations
9 Zone control
9 Group control (up and down buttons are added for group selection)
9 Control of HRV air flow direction and air flow rate
9 Expanded timer function
9 Malfunction code display
9 Maximum wiring length of 1,000m (total: 2,000m)
DCS301B51
Unified ON/OFF control
Providing simultaneous and individual control of 16 groups of indoor units
9 A maximum of 16 groups (128 indoor units) can be controlled
9 2 remote controls in separate locations can be used
9 Operating status indication (normal operation, alarm)
9 Centralised control indication
9 Maximum wiring length of 1,000m (total: 2,000m)
DST301B51
Schedule timer
Enabling 64 groups to be programmed
9 A maximum of 128 indoor units can be controlled
9 8 types of weekly schedule
9 A maximum of 48 hours back-up power supply
9 Maximum wiring length of 1,000m (total: 2,000m)
