LANGUAGES
English, French, German, Italian, Spanish
SYSTEM LAYOUT
9 Up to 2 x 64 indoor units can be controlled
9 Onboard Ethernet port (web browser & e-mail)
9 Digital i/o contacts (option)
9 Touch panel (full colour LCD via icon display)
MANAGEMENT
9 Web application & internet compatibility
- Monitoring & control according to user
- Remote monitoring & control of more than
one building
- Remote monitoring & control of more than
one building via internet
9 Power Proportional Distribution (option)
9 PPD data is available on the internet
9 Easy management of electricity consumption
9 Enhanced history function
CONTROL
9 Individual control (set point, start / stop, fan
speed) (max. 2 x 64 indoor units/groups)
9 Schedule control (8 schedules, 17 patterns)
9 Flexible grouping in zones
9 Yearly schedule
9 Fire emergency stop control
9 Interlocking control
9 Increased HRV monitoring and control function
9 Automatic cooling/heating changeover
9 Quick selection and full control
9 Simple navigation
9 Heating optimization
9 Temperature limit
9 Password security: 3 levels
(general, administration & service)
MONITORING
9 Visualisation via Graphical User Interface
(GUI)
9 Icon colour display change function
9 Indoor units operation mode
9 Error messages via e-mail & mobile phone
(option)
9 Indication filter replacement
9 Multi PC
COST PERFORMANCE
9 Labour saving
9 Easy installation
9 Compact design: limited installation space
9 Overall energy saving
OPEN INTERFACE
9 Communication to any third party controller
(domotics, BMS, etc.) is possible via open
interface.
CONNECTABLE TO
9 VRV
9 HRV
9 Sky Air (via interface adapter)
9 Split (via interface adapter)
p. 71
