<Outside the Range>: When the value of a transaction is beyond a certain range, it will be

marked as an exception. The range need to be defined in the following sub-setting

<Value> and <Value (Upper Limit)>.

NOTE: Transactions will be marked as exceptions in text database only when: (1)

“Exception Strings” and “By Numerals” are set and (2) “Trigger” is <ON>. The data

stored before hand will not be marked as exceptions.

3.7.4 Input Setup

This item is used to configure the connection settings of the POS device.

Input Setup

1. Port Selection

2. Input Source

3. Camera Selection

4. Text Filter

5. Manual Filter Setup

6. Input Process

7. Text Baud Rate

8. Text Bits

9. Text Stop

10. Text Parity

Serial Port

Direct Connected

ASCII

Canonical

9600

None

Port Selection

It is essential to select a correct port for the POS device. Meanwhile, make sure the POS

device is connected to the port selected.

Input Source

Select the input source of the POS device, either direct connected or connected with the

Data Converter.

Camera Selection

Select a camera to display the text overlay.

Text Filter

This item is used to choose the text filter. The supported models for pole display and printer

are listed as below.

Pole Display Printer POS Machine

Cache Technology VFD-202T Citizen CBM-1000 II Acula AQ-812

Citizen C2202 Citizen CT-S300 IBM SurePOS 700

Digipos CD5220 Dell T200 Samsung ER-380M

Emax Pole Display Epson TM-T88II/TM-T88III/TM-T88IV Samsung ER-655
