- 66 -
Appendix E: Simultaneous Output Options
The monitor functionality differs for VGA + digital output and dual VGA models. There are four
different conditions. When simultaneous output is enabled, three resolutions are selectable. If
simultaneous output is not enabled, only one resolution is available. Refer to the following tables to see
which monitors are functional under the four different conditions for the two different types of models.
For VGA + digital output models:
VGA + Digital Output
Simultaneous
Output
Resolution
Digital
Output
VGA
BNC
Main
BNC
Call
S-Video
Hybrid Display
on VGA
Playback
On VGA
Dual
Main
Enabled 800 X 600 O O O O O O O -
Enabled 1024 X 768 O O - O - O O -
Enabled 1280 X 1024 O O - O - O O -
Disabled 800 X 600 O O O O O - - O
For dual VGA models:
Dual VGA
Simultaneous
Output
Resolution VGA 1 VGA 2
BNC
Main
BNC
Call
S-Video
Hybrid Display
on VGA 2
Playback
On VGA 2
Dual
Main
Enabled 800 X 600 - O O O O O O -
Enabled 1024 X 768 - O - O - O O -
Enabled 1280 X 1024 - O - O - O O -
Disabled 800 X 600 O O O O O - - O
*O represents the monitor is functional.
**- represents the monitor is not functional.
Refer to the OSD setup manual for detailed settings.
