Planet HDVR-1600 [37/74] Search recorded video

Follow the steps to control the call monitor.

• Press the CALL key on the front panel to enter call monitor control mode. The message “Call

Mode” will be shown on the bottom-left of the screen.

Press 1-16 Key To Select Channel

Press SEQ To Enable Sequence

Call Mode

• Press CHANNEL key to display the associated camera on call monitor.

• Alternatively, press SEQ repeatedly to display the sequence of cameras previously

programmed in Call Monitor Schedule menu.

• Press ESC to return the front panel to Main monitor control mode.

4.3 Search Recorded Video

The DVR is capable of searching and playing back recorded video by date / time, events, or text.

In live or playback mode, press SEARCH to enter the Search menu, which is shown as follows.

----------------------------Search By Time----------------------------

From:

End:

Select:

2008/01/01 00:00:00

2008/05/01 00:00:00

2008/01/01 00:00:00

Begin Playback

----------------------------Search By Event----------------------------

Select Channel: CH1 CH2 CH3 CH4

Event List

-----------------------------Search By Text-----------------------------

Text Query Page

NOTE: “Search By Text” only functions when a POS machine is connected and text data is

stored.

4.3.1 Search by Time

Follow the steps to search video by date and time.

• Press SEARCH key to enter the Search menu.

• Move the cursor to “From Time” and press ENTER will start playing recorded video from the

specified “From Time”.

• Move the cursor to “End Time” and press ENTER will start playing recorded video from the

specified “End Time”.

• Use Direction keys to move the cursor for setting the start time. Adjust the date and time values

by UP / DOWN keys.

• Press ENTER to confirm the settings or ESC to abort.

• Move the cursor to <Begin Playback> and press ENTER to start playing back the selected

video.
