![Planet HDVR-1600 [39/74] Search by text](/views2/1071453/page39/bg27.png)
- 39 -
4.3.3 Search by Text
When a POS device is connected to the DVR, users can search for videos with text data. The
“Text Query Page” is displayed as below:
Text Query Page
By Text
Item
Item
By Numerals
Value
Value (Upper Limit)
By Date/Time
From:
To:
By Channel
OFF
OFF
OFF
2008/01/01 AM00:00:00
2008/05/01 AM00:00:00
OFF
Text Query List
There are three ways to search: by text, by numerals, or by text and numerals. In the mean
time, date/time and/or channel can be specified to narrow down range, thus the search will be
faster. Refer to below for search options.
By Text
:
• Exception: Search for video with data containing the exception string set in the OSD setup
menu.
• OR: Enter two sets of word strings. Search for videos with data containing EITHER ONE of the
word strings.
• AND: Enter two sets of word strings. Search for videos with data containing BOTH of the word
strings.
• Specific: Specify one set of word string. Search for videos with data containing the specific
word string.
By Numerals
:
• Outside The Range: Enter two numbers to specify a range. Search for videos with data
containing number(s) out of the range.
• Inside The Range: Enter two numbers to specify a range. Search for videos with data
containing number(s) within the range.
• Less Equal Than: Enter one number. Search for videos with data containing number(s) less
than or equal to the specific number.
• Greater Equal Than: Enter one number. Search for videos with data containing number(s)
greater than or equal to the specific number.
• Specific: Specify a number. Search for videos with data containing the specific number.
