- 63 -

The keys of the remote control function as the keys of the front panel of the DVR. The difference

between the remote control and the front panel is the “DVR SEL” key. The DVR Selection key is used to

switch control between different DVRs.

The remote control can be used to control up to 16 DVRs. To setup the remote control, the first

thing is to assign a unique DVR Unit ID to different DVRs.

Use the front panel of the DVR, and follow this path to change the DVR Unit ID, <Main Menu> Æ

<System Setup> Æ <RS485 Setup> Æ <Unit ID>. Change the DVR Unit ID to any number between

224 and 239, and exit the menu.

The ID Table is listed below for reference.

DVR Unit ID 224 225 226 227 228 229 230 231

Remote Control # 1 2 3 4 5 6 7 8

DVR Unit ID 232 233 234 235 236 237 238 239

Remote Control # 9 10 11 12 13 14 15 16

After the DVR Unit ID is changed, setup the “DVR SEL” of the remote control. Press “DVR SEL”,

and then press the Remote Control # immediately to select the DVR. For example, assuming that the

DVR Unit ID is set to 225, press “DVR SEL” and press “2” immediately. Now, the remote control will

only be able to control the specified DVR. Press “DVR SEL”, and then press the Remote control # to

switch between DVRs.

To exit the single DVR control mode, press “DVR SEL”, and then press “ESC” to do so.
