VIP-2100 User’s manual - 5 -
7
T1 CAS DTMF/R1MF
E&M Bell Core Feature Group D,
Wink Start, E&M Delay Start, E&M
Feature Group A Immediate Start,
E&M Feature Group B Wink Start,
E&M Feature Group D Wink
Start(ANI B4 ADDR), E&M Feature
Group D Wink Start, E&M
Immediate Start, E&M Wink Start,
GroundStart FXO, GroundStart
FXS, Loop Start FXO, Loop Start
FXS, Loop Start FXO Hot-Line
8
T1 ISDN PRI Support
NI2 ISDN,5ESS 10 ISDN,DMS100
ISDN, NTT ISDN (INS-1500), Hong
Kong, QSIC
9
Trunk Spans
1 (T1/E1s) per chassis
10
Default Trunk Channel Mask
Yes
11
PSTN Line Hunting
Yes
12
PSTN Line Hunting Channel Selection
Yes
13
On the Fly Reset Channel/Trunk
Yes
Audio Codec Support
1
G.711 A-law
Yes
2
G.711 u-law
Yes
3
G.723.1
Yes (5.3/6.3K)
4
G.729A
Yes
5
Selectable Payload Size - G.711
20, 40, 60 ms
6
Selectable Payload Size - G.723
30, 60, 90 ms
7
Selectable Payload Size - G.729
20, 40, 60 ms
Fax Transmission
1
Bypass mode
Yes
2
CISCO Compatible
Yes
3
ECM Support
Yes
4
FAX auto-detection
Yes
5
H.323 Annex D Support
Yes
6
SIP- T.38 Reinvite
Yes
7
T.38 During fast connect
Yes
8
T.38 Redundant Packet
0-2
9
Transparent mode
Yes
10
Up to G3 FAX
Yes (up to 14400 bps)
DTMF Transmission
1
RFC 2833
Yes
2
H.245 Alphanumeric mode
Yes
3
H.245 Signal mode
Yes
4
Q.931 UUI Yes
5
SIP INFO Yes
6
Transparent mode Yes
Voice Quality & Echo Cancellation
1
Adaptive Jitter Buffer
Yes
2
CNG
Yes
