Planet VIP-2400 [105/140] One stage dialing gatekeeper mode

VIP-2100 User’s manual - 100 -

Appendix 1 Call Flow Example

One Stage Dialing (Gatekeeper Mode)

Example Description:

Components Contents

Start

Component ID:

1000

Next Component: 1001

CTB

Component ID:

1001

PSTN To: 1004

H.323 To: 1007

SIP To: 1005

1007 Route for H.323Gatekeeper call

MakeCall

Component ID:

1007

Route Mode: PSTN

Finish To: 1005

Failed Other To: 1005

Disc

Component ID:

1005

Reason: PSTN normal call clear

Next Component: 1006

Quit
