Planet VIP-2400 [84/140] Prompt manager

VIP-2100 User’s manual - 79 -

• Community Name: Community name for network manager system

accessing

• Access Rights: Giving access right to the community

Start path: Click Control→SNMP→Trap

Figure 8.4-2

Parameter:

• Trap Community: Trap community name for NMS

• Trap Host: Trap host IP address

JNote: It takes around 1-minute to update SNMP configuration and

display successful message.

Prompt Manager

Start path: Click Control→Prompt Manager

Figure 8.4-1
