VIP-2100 User’s manual - 43 -
Chapter 5 Peer to Peer Mode Configuration
Environment used in this chapter
Process:
PSTN → H.323 Call: DNIS (822656991001) → DM (PSTN In Drop) →Make
H.323 - Peer to Peer Call (1001)
→ SIP Call: DNIS (822656998888) → DM (PSTN In Drop) →Make
SIP - Peer to Peer Call (8888)
H.323 → DNIS (50932123321) → DM (H.323_in_drop) → Make Call
(0932123321)
SIP → DNIS (1130028610825123) → DM (SIP_in_drop) → Make Call
(0028610825123)
☺Digit Manipulation: Please refer section “Digit Manipulation”
Network Configuration
Please refer to section “Network Configuration”
Account Manager
Please refer to section “Account Manager”
Interface Configuration
Please refer to section “Interface Configuration”
H323 VoIP
Network
Peer to Peer
H.323
Gateway
Phone 1001
SIP VoIP
Net
work
H323
Phone
SIP USB Phone 8888
SIP
Phone
