VIP-2100 User’s manual - 119 -
(GMT+02:00) Athens, Istanbul, Minsk 34. GTB Standard Time
(GMT+03:00) Nairobi 22. E. Africa Standard Time
(GMT+03:00) Moscow, St. Petersburg, Volgograd
54. Russian Standard Time
(GMT+03:00) Kuwait, Riyadh 03. Arab Standard Time
(GMT+03:00) Baghdad 05. Arabic Standard Time
(GMT+03:30) Tehran 37. Iran Standard Time
(GMT+04:00) Baku, Tbilisi, Yerevan 12. Caucasus Standard Time
(GMT+04:00) Abu Dhabi, Muscat 04. Arabian Standard Time
(GMT+04:30) Kabul 01. Afghanistan Standard Time
(GMT+05:00) Islamabad, Karachi, Tashkent 73. West Asia Standard Time
(GMT+05:00) Ekaterinburg 28. Ekaterinburg Standard Time
(GMT+05:30) Chennai, Kolkata, Mumbai, New
Delhi
36. India Standard Time
(GMT+05:45) Kathmandu 46. Nepal Standard Time
(GMT+06:00) Sri Jayawardenepura 62. Sri Lanka Standard Time
(GMT+06:00) Astana, Dhaka 15. Central Asia Standard Time
(GMT+06:00) Almaty, Novosibirsk 45. N. Central Asia Standard Time
(GMT+06:30) Rangoon 44. Myanmar Standard Time
(GMT+07:00) Krasnoyarsk 50. North Asia Standard Time
(GMT+07:00) Bangkok, Hanoi, Jakarta 59. SE Asia Standard Time
(GMT+08:00) Taipei 63. Taipei Standard Time
(GMT+08:00) Perth 70. W. Australia Standard Time
(GMT+08:00) Kuala Lumpur, Singapore 60. Singapore Standard Time
(GMT+08:00) Irkutsk, Ulaan Bataar 49. North Asia East Standard Time
(GMT+08:00) Beijing, Chongqing, Hong Kong,
Urumqi
20. China Standard Time
(GMT+09:00) Yakutsk 75. Yakutsk Standard Time
(GMT+09:00) Seoul 39. Korea Standard Time
(GMT+09:00) Osaka, Sapporo, Tokyo 65. Tokyo Standard Time
(GMT+09:30) Darwin 07. AUS Central Standard Time
(GMT+09:30) Adelaide 13. Cen. Australia Standard Time
(GMT+10:00) Vladivostok 69. Vladivostok Standard Time
(GMT+10:00) Hobart 64. Tasmania Standard Time
(GMT+10:00) Guam, Port Moresby 74. West Pacific Standard Time
(GMT+10:00) Canberra, Melbourne, Sydney 08. AUS Eastern Standard Time
(GMT+10:00) Brisbane 23. E. Australia Standard Tim
(GMT+11:00) Magadan, Solomon Is., New
Caledonia
18. Central Pacific Standard Time
(GMT+12:00) Fiji, Kamchatka, Marshall Is. 29. Fiji Standard Time
(GMT+12:00) Auckland, Wellington 47. New Zealand Standard Time
(GMT+13:00) Nuku'alofa 66. Tonga Standard Time
