VIP-2100 User’s manual - 98 -
Event Log:
Configure
LCD Display
▲ Previous event log
▼ Next event log
Enter Show detail event log
▲ Previous line
▼ Next line
ESC Quit detail event log viewing
ESC Quit to main menu
IP Config:
Configure
LCD Display
▲ Select Network configuration
▼ Select Network configuration
Enter Configure Network
▲ Increase the digit apply to network setting
▼ Decrease the digit apply to network setting
Enter Apply change to network information
ESC Quit network setting
ESC Quit to main menu
Reboot:
Configure
LCD Display
▲ Select Reboot or not
▼ Select Reboot or not
Enter Reset user: root’s (or admin) user password
ESC Quit Reboot configure
ESC Quit to main menu
Reset:
Configure
LCD Display
▲ Select user to change password
▼ Select user to change password
Enter Change user password
▲ Increase the alphabet apply to user password setting
▼ Decrease the alphabet apply to user password setting
ESC Quit Reset configure
ESC Quit to main menu
Soft Reset:
Configure
LCD Display
▲ Select Reset or not
▼ Select Reset or not
