VIP-2100 User’s manual - 8 -
7
H.323 to SIP FAX Relay
Yes
7
PSTN to H.323 Call
Yes
8
PSTN to PSTN Call
Yes
9
PSTN to SIP Call
Yes
10
SIP to H.323 Call
Yes
11
SIP to PSTN Call
Yes
12
SIP to SIP Call
Yes
13
SIP to SIP Fax Relay
Yes
14
VoIP to VoIP RTP unRouted
Yes
15
VoIP to VoIP RTP Routed
Yes
Enhance Service
1
ANI Access List
Yes
2
DNIS Access List
Yes
3
DID/DOD
Yes
4
PSTN Two Stage Dialing
Yes
5
VoIP Two Stage Dialing
Yes
6
Intelligent PSTN Call Routing
Yes (Random, Round Robin,
Priority)
7
In-trunk hunting method
Cyclic, random, rotary, reverse
cyclic, reverse rotary
8
Ring Back Tone Generation
Yes (per trunk enable/disable)
9
Call Progress Tone Support
Yes
10
Web-based Call Flow GUI
Drag and Drop interface, Full
control of call behavior (one-stage
or two-
stage dialing), IVR functions,
Support time duration play back
(Chinese & English), Power call
information branch, Collected
information validation, Active
disconnect & reconnect without
hang up, Selected disconnect
cause code & behavior
11
Play Credit Time Duration
Yes (Chinese & English)
12
Play Credit Balance
Yes (Chinese & English)
13
Almost-time-expired notify tone
Yes
14
IVR for PSTN
Yes
15
IVR for SIP
Yes
16
IVR for H.323
Yes
17
IP Access List
Yes
18
ANI Replacement
Yes
19
DNSI Replacement
Yes
AAA
1
Call detail record (CDR)
Yes
2
RADIUS Authentication
Yes
2
RADIUS Authorization
Yes
3
RADIUS Accounting
Yes
4
Redundant RADIUS Server Support
Yes, Active/Standby/Auto Failover
5
PSTN Prepaid Support
Yes
