Multi-Homing Security Gateway User’s Manual

Step 2: Configure the parameters

Source Address: Select names of the WAN networks from the drop down list. The drop down

list contains the names of all WAN networks defined in the WAN section of the Address menu.

To create a new source address, please go to the LAN section under the Address menu.

Destination Address: Select names of the LAN networks from the drop down list. The drop

down list contains the names of IP mapping addresses specified in the Mapped IP or the Virtual

Server sections of Virtual Server menu. To create a new destination address, please go to the

Virtual Server menu.

Service: Specified services provided by LAN network servers. These are services / application

that are allowed to pass from the network to the LAN network. Choose ANY for all services.

Schedule: Select the item listed in the schedule to enable the policy to automatically execute

the function in a certain time and range.

Trunk: Check to allow VPN traffic passing through.

Action: Select Permit or Deny ALL from the drop down list to allow or reject the packets

travelling between the specified WAN network and Virtual Server/Mapped IP.

Traffic Log: Select Enable to enable flow monitoring.

Statistics: Select Enable to enable flow statistics.

IDP: Check to enable IDP feature.

Max. Concurrent Sessions: The maximum concurrent sessions that allows to pass through

CS-1000. 0 means it is unlimited.

QoS: Select the item listed in the QoS to enable the policy to automatically execute the function

in a certain time and range.

NAT: Select enable to allow WAN user or DMZ user to access LAN resource using with LAN

interface’s IP address.

Step 3: Click OK to add new policy or click Cancel to cancel adding new incoming policy.

Modifying Incoming Policy

Step 1: In the Incoming window, locate the name of policy desired to be modified and click its corresponding

Modify option in the Configure field.

Step 2: In the Modify Policy window, fill in new settings.

Step 3: Click OK to save modifications or click Cancel to cancel modifications.

- 164 -
