Multi-Homing Security Gateway User’s Manual

WAN No: WAN port 1 or 2.

Connect Mode: Display the current connection mode: PPPoE, Dynamic IP Address (Cable Modem User) or

Static IP Address.

IP Address: Display the current WAN IP Address.

Saturated Connections: Set the number for saturation whenever session numbers reach it, the CS-1000

switches to the next WAN port on the list. This function is only applicable for By Session mode.

Ping / HTTP: Display Ping/HTTP functions of WAN 1/2 to show if they are enabled or disabled.

Configure: Click Modify to modify WAN 1/2 settings.

Priority: Set priority of WAN 1/2 for Internet Access.

WAN 1/2 Interface

Using the WAN 1/2 Interface, the Administrator can sets up the WAN 1/2 network. These IP addresses are

real public IP Addresses, and are routable on the Internet.

Alive Indicator Site IP: This feature is used to ping an address for detecting WAN connection status.

Service: ICMP You can select an IP address by Assist, or type an IP address manually.

Service: DNS You can select a DNS IP and Domain name by Assist, or type the related data manually.

PPPoE (ADSL User): This option is for PPPoE users who are required to enter a username and password in

order to connect.

Username: Enter the PPPoE username provided by the ISP.

Password: Enter the PPPoE password provided by the ISP.

IP Address provided by ISP:

Dynamic: Select this if the IP address is automatically assigned by the ISP.

Fixed: Select this if you were given a static IP address. Enter the IP address that is given to you by

your ISP.

Max. Upstream/Downstream Bandwidth: The bandwidth provided by ISP.

Auto Disconnect: The PPPoE connection will automatically disconnect after a length of idle time (no

activities). Enter in the amount of idle minutes before disconnection. Enter ‘0’ if you do not want the

PPPoE connection to disconnect at all.

Ping: Select this to allow the WAN 1 network to ping the IP Address of the Multi-Homing Security

Gateway. This will allow people from the Internet to be able to ping the Multi-Homing Security Gateway. If

it sets to enable, the device will respond to echo request packets from the WAN 1/2 network.

HTTP: Select this to allow the device WEBUI to be accessed from the WAN 1 network. This will allow

WebUI to be configured from a user on the Internet. Keep in mind that the device always requires a

username and password to enter the WebUI.
