- 6 -
Front Panel of 16-port KVM Switch:
PC Port Select
Bank Select
KVM-1600
16-Port KVM Switch
Bank Select
Reset
Bank No. Port No.
Port Select
Power
Current Active Bank Display
Current Active Port Display
Power On/Off
Rear Panel of 8-port KVM Switch:
Daisy Chain Port
Console Port Connector
KVM Port Connector
DC 12V
8
7
6 5
4
3 2 1
Console port
Daisy-chain in
PS/2 Mouse(Console)
VGA Monitor (Console) PS/2 Mouse (computer)
PS/2 Keyboard(Console) VGA Monitor (computer)
Power Adapter PS/2 Keyboard (computer)
Rear Panel of 16-port KVM Switch:
Daisy Chain Port
Console Port Connector
KVM Port Connector
DC 12V
Made in Taiwan
Daisy-chain in Console port
8
16
7
15
6
14
5
13
4
12
3
11
2
10
1
9
PS/2 Mouse(Console)
VGA Monitor (Console) PS/2 Mouse (computer)
PS/2 Keyboard(Console) VGA Monitor (computer)
Power Adapter PS/2 Keyboard (computer)
