- 5 -
2.2 Cable Diagrams
PS/2 Cable:
Mini Din 6 pin Male to Male
,
VGA Cable:
HDB15 pin Male to Male
AT to PS/2 keyboard
adapter: (Optional)
Din 5 pin Male to Mini Din
6 pin Female
PS2 to DB9 adapter (Op-
tional)
Mini Din 6 pin Female to
DB 9 pin Female
2.3 Product Details
Front Panel of 8-port KVM Switch:
PC Port Select
Bank Select
Current Active Bank Display
Current Active Port Display
Power On/Off
