Planet KVM-1600 [7/27] Technical specifications
![Planet KVM-1600 [7/27] Technical specifications](/views2/1071706/page7/bg7.png)
- 3 -
1.3 Technical Specifications
Model No. KVM-800 KVM-1600
PC Port 8 16
Console Port 1
Daisy Chain Port 1
PC Port Connector
(All Female Type)
PS/2 Keyboard mini Din 6 pin
PS/2 Mouse Mini Din 6 pin
VGA HDDB 15pin
Console Port Con-
nector
(All Female Type)
PS/2 Keyboard mini Din 6 pin
PS/2 Mouse Mini Din 6 pin
VGA HDDB 15pin
Daisy Chain Port
Connector
(All Female Type)
PS/2 Keyboard mini Din 6 pin
PS/2 Mouse Mini Din 6 pin
VGA HDDB 15pin
PC selection On Screen Display Menu, Hot Key, Push Button
7 segment LED One Bank LED, Two PC Port LEDs
On Screen Display
Control
Yes
Scan Intervals 5~99 Sec.
Keyboard Emula-
tion
PS2
Mouse Emulation PS2
VGA Resolution Up to 1920X1440
Bandwidth 200MHz
MAX PC Connec-
tion
120 128
Housing Metal
Power Adapter DC 12V 1A or DC 9V 1A
Operation Temp. 0 ~ 40 degree C (32 ~ 104degree F)
Storage Temp. -20 ~ 60 degree C (-4 ~ 140 degree F)
Humidity 0~80% RH, Non-Condensing
Size 19” Rack Mount / 1RU 19” Rack Mount / 2RU
Weight (kg) 2.3 4.1
Dimension (mm) 410(L) x 172(W) x 44(H) 410(L) x 172(W) x 88(H)
