- 4 -
CHAPTER 2 INSTALLATION
2.1 System Requirements
KVM-800
Model No. 8 port KVM Switch
Console side One VGA Monitor
One PS/2 Keyboard
One PS/2 Mouse
Computer side 8 HDDB 15 pin male to male VGA cables
8 PS/2 cables male to male for Keyboard
8 PS/2 cables male to male for Mouse
Optional USB-PS/2 adapter for multi-platform PC /
iMAC / Sun
KVM-1600
Model No. 16 port KVM Switch
Console side One VGA Monitor
One PS/2 Keyboard
One PS/2 Mouse
Computer side 16 HDDB 15 pin male to male VGA cables
16 PS/2 cables male to male for Keyboard
16 PS/2 cables male to male for Mouse
Optional USB-PS/2 adapter for multi-platform PC /
iMAC / Sun
