- 17 -
3.4 On Screen Display Operation
When you pop up the OSD menu window, go through the hot
key, you will see the following small window on your monitor.
a. The 1
ST
line bar is Bank no.
b. The 2nd block is your PC system name list. You will find
the system number list from 01 to 08. You can define your
PC name in maximum 8 characters. The factory default
of 8 port KVM switch is from “SYSTEM 01”, “SYSTEM
02”,…, “SYSTEM 08”. Besides, the sun symbol “ ☼ “ near
to the PC name represents the PC system is powered on.
c. Use up arrow key “ y “ or down arrow key “ z “ to select
port for destination PC name. After you have selected the
PC port already, you can press the ENTER Key to switch
the PC port you want immediately
BANK : 1
01 ☼SYSTEM 01 02 SYSTEM 02
03 SYSTEM 03 ☼SYSTEM 04
05 SYSTEM 05 06 SYSTEM 06
07 SYSTEM 07 08 ☼SYSTEM 08
OSD : 1 0 SEC. CHANGE PASSWORD
ESC : QUIT ENTER : COMPLETE
TAB : NEXT INSERT : EDIT
©/ª: SELECT PORT
PgDn/PgUp: BANK SELECT
SCAN: 1 0 SEC. CONSOLE ON/OFF
04
