• Системы VRV
®
• Наружный блок
13
• Наружный блок • VRV
®
III с тепл. нас., комбинация с выс. знач. COP • RXYHQ-P9
5 Таблицы производительности
5 - 2 Таблицы холодопроизводительности
RXYHQ12P
4TW31462-3
TC: Total Capacity: kW ; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacity
index
Outdoor
air temp.
(°CDB)
Indoor air temperature: °CB
14.0 16.0 18.0 19.0 20.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90% 270.0 10 20.3 2.66 24.3 3.20 28.2 3.78 30.2 4.08 32.1 4.39 36.0 5.01 40.0 5.65
12 20.3 2.70 24.3 3.26 28.2 3.85 30.2 4.16 32.1 4.47 36.0 5.10 40.0 5.75
14 20.3 2.75 24.3 3.32 28.2 3.92 30.2 4.24 32.1 4.55 36.0 5.20 40.0 5.86
16 20.3 2.80 24.3 3.38 28.2 4.00 30.2 4.32 32.1 4.64 36.0 5.30 39.9 5.96
18 20.3 2.85 24.3 3.44 28.2 4.08 30.2 4.40 32.1 4.73 36.0 5.41 39.3 6.15
20 20.3 2.90 24.3 3.51 28.2 4.16 30.2 4.49 32.1 4.91 36.0 5.81 38.8 6.44
21 20.3 2.93 24.3 3.55 28.2 4.23 30.2 4.65 32.1 5.09 36.0 6.02 38.5 6.59
23 20.3 2.98 24.3 3.69 28.2 4.53 30.2 4.98 32.1 5.45 36.0 6.46 38.0 6.90
25 20.3 3.14 24.3 3.94 28.2 4.84 30.2 5.32 32.1 5.83 36.0 6.92 37.4 7.20
27 20.3 3.34 24.3 4.20 28.2 5.17 30.2 5.69 32.1 6.23 36.0 7.40 36.9 7.50
29 20.3 3.56 24.3 4.48 28.2 5.51 30.2 6.07 32.1 6.66 35.6 7.75 36.3 7.80
31 20.3 3.78 24.3 4.77 28.2 5.88 30.2 6.48 32.1 7.10 35.1 8.05 35.8 8.11
33 20.3 4.02 24.3 5.08 28.2 6.26 30.2 6.90 32.1 7.58 34.5 8.35 35.3 8.41
35 20.3 4.26 24.3 5.40 28.2 6.67 30.2 7.36 32.1 8.08 34.0 8.65 34.7 8.72
37 20.3 4.53 24.3 5.74 28.2 7.10 30.2 7.83 32.1 8.61 33.4 8.96 34.2 9.03
39 20.3 4.80 24.3 6.10 28.2 7.55 30.2 8.34 32.1 9.17 32.9 9.3 33.6 9.3
80% 240.0 10 18.1 2.36 21.6 2.82 25.1 3.32 26.8 3.57 28.5 3.84 32.0 4.37 35.5 4.93
12 18.1 2.40 21.6 2.87 25.1 3.38 26.8 3.64 28.5 3.91 32.0 4.45 35.5 5.02
14 18.1 2.44 21.6 2.92 25.1 3.44 26.8 3.71 28.5 3.98 32.0 4.54 35.5 5.12
16 18.1 2.48 21.6 2.97 25.1 3.50 26.8 3.78 28.5 4.06 32.0 4.63 35.5 5.22
18 18.1 2.52 21.6 3.03 25.1 3.57 26.8 3.85 28.5 4.13 32.0 4.72 35.5 5.32
20 18.1 2.56 21.6 3.09 25.1 3.64 26.8 3.92 28.5 4.22 32.0 4.89 35.5 5.69
21 18.1 2.59 21.6 3.11 25.1 3.67 26.8 3.96 28.5 4.30 32.0 5.07 35.5 5.89
23 18.1 2.63 21.6 3.18 25.1 3.85 26.8 4.22 28.5 4.61 32.0 5.43 35.5 6.32
25 18.1 2.72 21.6 3.38 25.1 4.11 26.8 4.51 28.5 4.92 32.0 5.81 35.5 6.77
27 18.1 2.89 21.6 3.60 25.1 4.39 26.8 4.81 28.5 5.26 32.0 6.21 35.5 7.24
29 18.1 3.07 21.6 3.83 25.1 4.68 26.8 5.13 28.5 5.61 32.0 6.63 35.5 7.74
31 18.1 3.26 21.6 4.08 25.1 4.98 26.8 5.47 28.5 5.98 32.0 7.08 35.0 8.04
33 18.1 3.46 21.6 4.33 25.1 5.30 26.8 5.83 28.5 6.38 32.0 7.55 34.4 8.34
35 18.1 3.67 21.6 4.60 25.1 5.64 26.8 6.20 28.5 6.79 32.0 8.05 33.9 8.65
37 18.1 3.89 21.6 4.89 25.1 6.00 26.8 6.60 28.5 7.23 32.0 8.57 33.3 8.95
39 18.1 4.13 21.6 5.19 25.1 6.38 26.8 7.02 28.5 7.69 32.0 9.14 32.8 9.3
70% 210.0 10 15.8 2.07 18.9 2.46 21.9 2.87 23.5 3.09 25.0 3.30 28.0 3.76 31.1 4.22
12 15.8 2.10 18.9 2.50 21.9 2.92 23.5 3.14 25.0 3.36 28.0 3.83 31.1 4.30
14 15.8 2.14 18.9 2.54 21.9 2.97 23.5 3.20 25.0 3.43 28.0 3.90 31.1 4.38
16 15.8 2.17 18.9 2.59 21.9 3.03 23.5 3.26 25.0 3.49 28.0 3.97 31.1 4.47
18 15.8 2.21 18.9 2.63 21.9 3.08 23.5 3.32 25.0 3.56 28.0 4.05 31.1 4.56
20 15.8 2.24 18.9 2.68 21.9 3.14 23.5 3.38 25.0 3.63 28.0 4.13 31.1 4.68
21 15.8 2.26 18.9 2.70 21.9 3.17 23.5 3.41 25.0 3.66 28.0 4.19 31.1 4.85
23 15.8 2.30 18.9 2.75 21.9 3.24 23.5 3.53 25.0 3.84 28.0 4.49 31.1 5.20
25 15.8 2.34 18.9 2.86 21.9 3.45 23.5 3.77 25.0 4.10 28.0 4.80 31.1 5.56
27 15.8 2.48 18.9 3.05 21.9 3.68 23.5 4.02 25.0 4.37 28.0 5.12 31.1 5.94
29 15.8 2.63 18.9 3.24 21.9 3.91 23.5 4.28 25.0 4.66 28.0 5.47 31.1 6.34
31 15.8 2.79 18.9 3.44 21.9 4.16 23.5 4.55 25.0 4.96 28.0 5.83 31.1 6.77
33 15.8 2.95 18.9 3.65 21.9 4.43 23.5 4.84 25.0 5.28 28.0 6.21 31.1 7.22
35 15.8 3.13 18.9 3.87 21.9 4.70 23.5 5.15 25.0 5.62 28.0 6.61 31.1 7.69
37 15.8 3.31 18.9 4.11 21.9 5.00 23.5 5.47 25.0 5.97 28.0 7.04 31.1 8.19
39 15.8 3.51 18.9 4.36 21.9 5.30 23.5 5.81 25.0 6.35 28.0 7.49 31.1 8.73
60% 180.0 10 13.6 1.80 16.2 2.12 18.8 2.45 20.1 2.62 21.4 2.80 24.0 3.17 26.6 3.55
12 13.6 1.83 16.2 2.15 18.8 2.49 20.1 2.67 21.4 2.85 24.0 3.22 26.6 3.61
14 13.6 1.86 16.2 2.18 18.8 2.53 20.1 2.71 21.4 2.90 24.0 3.28 26.6 3.68
16 13.6 1.88 16.2 2.22 18.8 2.57 20.1 2.76 21.4 2.95 24.0 3.34 26.6 3.75
18 13.6 1.91 16.2 2.25 18.8 2.62 20.1 2.81 21.4 3.00 24.0 3.41 26.6 3.82
20 13.6 1.94 16.2 2.29 18.8 2.67 20.1 2.86 21.4 3.06 24.0 3.47 26.6 3.90
21 13.6 1.96 16.2 2.31 18.8 2.69 20.1 2.89 21.4 3.09 24.0 3.51 26.6 3.94
23 13.6 1.99 16.2 2.35 18.8 2.74 20.1 2.94 21.4 3.15 24.0 3.64 26.6 4.18
25 13.6 2.02 16.2 2.40 18.8 2.85 20.1 3.09 21.4 3.35 24.0 3.89 26.6 4.47
27 13.6 2.10 16.2 2.54 18.8 3.03 20.1 3.29 21.4 3.57 24.0 4.15 26.6 4.77
29 13.6 2.22 16.2 2.70 18.8 3.22 20.1 3.50 21.4 3.80 24.0 4.42 26.6 5.09
31 13.6 2.35 16.2 2.86 18.8 3.42 20.1 3.72 21.4 4.04 24.0 4.70 26.6 5.42
33 13.6 2.49 16.2 3.03 18.8 3.63 20.1 3.95 21.4 4.29 24.0 5.00 26.6 5.78
35 13.6 2.63 16.2 3.21 18.8 3.85 20.1 4.20 21.4 4.56 24.0 5.32 26.6 6.15
37 13.6 2.78 16.2 3.40 18.8 4.09 20.1 4.45 21.4 4.84 24.0 5.66 26.6 6.54
39 13.6 2.94 16.2 3.60 18.8 4.33 20.1 4.73 21.4 5.14 24.0 6.01 26.6 6.96
50% 150.0 10 11.3 1.55 13.5 1.79 15.7 2.05 16.8 2.19 17.8 2.33 20.0 2.61 22.2 2.91
12 11.3 1.57 13.5 1.82 15.7 2.08 16.8 2.22 17.8 2.36 20.0 2.66 22.2 2.96
14 11.3 1.59 13.5 1.85 15.7 2.12 16.8 2.26 17.8 2.40 20.0 2.70 22.2 3.01
16 11.3 1.61 13.5 1.87 15.7 2.15 16.8 2.29 17.8 2.44 20.0 2.75 22.2 3.07
18 11.3 1.63 13.5 1.90 15.7 2.19 16.8 2.33 17.8 2.48 20.0 2.80 22.2 3.12
20 11.3 1.66 13.5 1.93 15.7 2.22 16.8 2.37 17.8 2.53 20.0 2.85 22.2 3.18
21 11.3 1.67 13.5 1.95 15.7 2.24 16.8 2.39 17.8 2.55 20.0 2.88 22.2 3.21
23 11.3 1.70 13.5 1.98 15.7 2.28 16.8 2.44 17.8 2.60 20.0 2.93 22.2 3.29
25 11.3 1.72 13.5 2.01 15.7 2.32 16.8 2.49 17.8 2.68 20.0 3.08 22.2 3.51
27 11.3 1.75 13.5 2.08 15.7 2.45 16.8 2.64 17.8 2.85 20.0 3.28 22.2 3.74
29 11.3 1.85 13.5 2.21 15.7 2.60 16.8 2.81 17.8 3.02 20.0 3.48 22.2 3.98
31 11.3 1.95 13.5 2.34 15.7 2.76 16.8 2.98 17.8 3.21 20.0 3.70 22.2 4.23
33 11.3 2.06 13.5 2.47 15.7 2.92 16.8 3.16 17.8 3.41 20.0 3.93 22.2 4.50
35 11.3 2.18 13.5 2.61 15.7 3.09 16.8 3.35 17.8 3.61 20.0 4.18 22.2 4.78
37 11.3 2.30 13.5 2.76 15.7 3.27 16.8 3.54 17.8 3.83 20.0 4.43 22.2 5.08
39 11.3 2.42 13.5 2.92 15.7 3.46 16.8 3.75 17.8 4.06 20.0 4.70 22.2 5.39
