Daikin RXYHQ24P9W1B [25/81] Таблицы производительности

Daikin RXYHQ24P9W1B [25/81] Таблицы производительности
• Системы VRV
®
• Наружный блок
23
• Наружный блок • VRV
®
III с тепл. нас., комбинация с выс. знач. COP • RXYHQ-P9
5 Таблицы производительности
5 - 2 Таблицы холодопроизводительности
RXYHQ24P
4TW31462-3
TC: Total Capacity: kW ; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacity
index
Outdoor
air temp.
(°CDB)
Indoor air temperature: °CB
14.0 16.0 18.0 19.0 20.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90% 540.0 10 40.7 4.81 48.5 5.80 56.4 6.85 60.3 7.4 64.2 7.9 72.1 9.1 79.9 10.2
12 40.7 4.89 48.5 5.91 56.4 6.98 60.3 7.5 64.2 8.1 72.1 9.2 79.9 10.4
14 40.7 4.98 48.5 6.01 56.4 7.11 60.3 7.7 64.2 8.3 72.1 9.4 79.9 10.6
16 40.7 5.07 48.5 6.12 56.4 7.24 60.3 7.8 64.2 8.4 72.1 9.6 79.9 10.8
18 40.7 5.16 48.5 6.24 56.4 7.4 60.3 8.0 64.2 8.6 72.1 9.8 79.1 11.2
20 40.7 5.25 48.5 6.36 56.4 7.5 60.3 8.1 64.2 8.9 72.1 10.5 78.0 11.8
21 40.7 5.30 48.5 6.42 56.4 7.7 60.3 8.4 64.2 9.2 72.1 10.9 77.4 12.1
23 40.7 5.40 48.5 6.69 56.4 8.2 60.3 9.0 64.2 9.9 72.1 11.7 76.3 12.6
25 40.7 5.69 48.5 7.14 56.4 8.8 60.3 9.6 64.2 10.6 72.1 12.5 75.2 13.2
27 40.7 6.06 48.5 7.6 56.4 9.4 60.3 10.3 64.2 11.3 72.1 13.4 74.1 13.7
29 40.7 6.44 48.5 8.1 56.4 10.0 60.3 11.0 64.2 12.1 71.6 14.2 73.0 14.3
31 40.7 6.85 48.5 8.6 56.4 10.6 60.3 11.7 64.2 12.9 70.5 14.7 71.9 14.8
33 40.7 7.28 48.5 9.2 56.4 11.3 60.3 12.5 64.2 13.7 69.4 15.3 70.8 15.4
35 40.7 7.7 48.5 9.8 56.4 12.1 60.3 13.3 64.2 14.6 68.3 15.8 69.7 15.9
37 40.7 8.2 48.5 10.4 56.4 12.9 60.3 14.2 64.2 15.6 67.2 16.4 68.6 16.5
39 40.7 8.7 48.5 11.0 56.4 13.7 60.3 15.1 64.2 16.6 66.1 16.9 67.5 17.1
80% 480.0 10 36.2 4.27 43.1 5.11 50.1 6.01 53.6 6.47 57.1 6.95 64.1 7.9 71.0 8.9
12 36.2 4.34 43.1 5.20 50.1 6.12 53.6 6.59 57.1 7.08 64.1 8.1 71.0 9.1
14 36.2 4.41 43.1 5.29 50.1 6.23 53.6 6.71 57.1 7.21 64.1 8.2 71.0 9.3
16 36.2 4.49 43.1 5.39 50.1 6.35 53.6 6.84 57.1 7.3 64.1 8.4 71.0 9.5
18 36.2 4.56 43.1 5.49 50.1 6.47 53.6 6.97 57.1 7.5 64.1 8.6 71.0 9.6
20 36.2 4.65 43.1 5.59 50.1 6.59 53.6 7.11 57.1 7.6 64.1 8.9 71.0 10.3
21 36.2 4.69 43.1 5.64 50.1 6.66 53.6 7.18 57.1 7.8 64.1 9.2 71.0 10.7
23 36.2 4.77 43.1 5.75 50.1 6.98 53.6 7.6 57.1 8.3 64.1 9.8 71.0 11.5
25 36.2 4.93 43.1 6.12 50.1 7.5 53.6 8.2 57.1 8.9 64.1 10.5 71.0 12.3
27 36.2 5.24 43.1 6.52 50.1 8.0 53.6 8.7 57.1 9.5 64.1 11.3 71.0 13.1
29 36.2 5.57 43.1 6.94 50.1 8.5 53.6 9.3 57.1 10.2 64.1 12.0 71.0 14.0
31 36.2 5.92 43.1 7.4 50.1 9.0 53.6 9.9 57.1 10.8 64.1 12.8 70.3 14.7
33 36.2 6.28 43.1 7.9 50.1 9.6 53.6 10.6 57.1 11.6 64.1 13.7 69.2 15.2
35 36.2 6.66 43.1 8.3 50.1 10.2 53.6 11.2 57.1 12.3 64.1 14.6 68.1 15.8
37 36.2 7.06 43.1 8.9 50.1 10.9 53.6 12.0 57.1 13.1 64.1 15.5 67.0 16.4
39 36.2 7.5 43.1 9.4 50.1 11.6 53.6 12.7 57.1 13.9 64.1 16.6 65.9 16.9
70% 420.0 10 31.7 3.76 37.8 4.46 43.9 5.20 46.9 5.59 50.0 5.99 56.0 6.81 62.1 7.7
12 31.7 3.81 37.8 4.53 43.9 5.29 46.9 5.69 50.0 6.10 56.0 6.93 62.1 7.8
14 31.7 3.87 37.8 4.61 43.9 5.39 46.9 5.79 50.0 6.21 56.0 7.06 62.1 7.9
16 31.7 3.93 37.8 4.69 43.9 5.48 46.9 5.90 50.0 6.32 56.0 7.20 62.1 8.1
18 31.7 4.00 37.8 4.77 43.9 5.58 46.9 6.01 50.0 6.44 56.0 7.3 62.1 8.3
20 31.7 4.07 37.8 4.85 43.9 5.69 46.9 6.12 50.0 6.57 56.0 7.5 62.1 8.5
21 31.7 4.10 37.8 4.90 43.9 5.74 46.9 6.18 50.0 6.63 56.0 7.6 62.1 8.8
23 31.7 4.17 37.8 4.99 43.9 5.86 46.9 6.39 50.0 6.95 56.0 8.1 62.1 9.4
25 31.7 4.25 37.8 5.19 43.9 6.25 46.9 6.82 50.0 7.4 56.0 8.7 62.1 10.1
27 31.7 4.49 37.8 5.52 43.9 6.66 46.9 7.28 50.0 7.9 56.0 9.3 62.1 10.8
29 31.7 4.76 37.8 5.87 43.9 7.09 46.9 7.8 50.0 8.4 56.0 9.9 62.1 11.5
31 31.7 5.05 37.8 6.23 43.9 7.5 46.9 8.3 50.0 9.0 56.0 10.6 62.1 12.3
33 31.7 5.35 37.8 6.62 43.9 8.0 46.9 8.8 50.0 9.6 56.0 11.3 62.1 13.1
35 31.7 5.67 37.8 7.02 43.9 8.5 46.9 9.3 50.0 10.2 56.0 12.0 62.1 13.9
37 31.7 6.00 37.8 7.4 43.9 9.1 46.9 9.9 50.0 10.8 56.0 12.8 62.1 14.8
39 31.7 6.35 37.8 7.9 43.9 9.6 46.9 10.5 50.0 11.5 56.0 13.6 62.1 15.8
60% 360.0 10 27.1 3.27 32.4 3.83 37.6 4.44 40.2 4.75 42.8 5.07 48.0 5.74 53.3 6.43
12 27.1 3.31 32.4 3.89 37.6 4.51 40.2 4.83 42.8 5.16 48.0 5.84 53.3 6.55
14 27.1 3.36 32.4 3.96 37.6 4.59 40.2 4.91 42.8 5.25 48.0 5.95 53.3 6.67
16 27.1 3.41 32.4 4.02 37.6 4.66 40.2 5.00 42.8 5.34 48.0 6.06 53.3 6.79
18 27.1 3.46 32.4 4.09 37.6 4.75 40.2 5.09 42.8 5.44 48.0 6.17 53.3 6.92
20 27.1 3.52 32.4 4.15 37.6 4.83 40.2 5.18 42.8 5.54 48.0 6.29 53.3 7.06
21 27.1 3.55 32.4 4.19 37.6 4.88 40.2 5.23 42.8 5.60 48.0 6.35 53.3 7.13
23 27.1 3.60 32.4 4.26 37.6 4.97 40.2 5.33 42.8 5.71 48.0 6.60 53.3 7.6
25 27.1 3.66 32.4 4.34 37.6 5.16 40.2 5.60 42.8 6.06 48.0 7.04 53.3 8.1
27 27.1 3.80 32.4 4.60 37.6 5.49 40.2 5.97 42.8 6.46 48.0 7.5 53.3 8.6
29 27.1 4.02 32.4 4.89 37.6 5.84 40.2 6.35 42.8 6.88 48.0 8.0 53.3 9.2
31 27.1 4.26 32.4 5.18 37.6 6.20 40.2 6.74 42.8 7.3 48.0 8.5 53.3 9.8
33 27.1 4.51 32.4 5.49 37.6 6.58 40.2 7.16 42.8 7.8 48.0 9.1 53.3 10.5
35 27.1 4.77 32.4 5.82 37.6 6.98 40.2 7.6 42.8 8.3 48.0 9.6 53.3 11.1
37 27.1 5.04 32.4 6.16 37.6 7.4 40.2 8.1 42.8 8.8 48.0 10.3 53.3 11.9
39 27.1 5.32 32.4 6.52 37.6 7.9 40.2 8.6 42.8 9.3 48.0 10.9 53.3 12.6
50% 300.0 10 22.6 2.81 27.0 3.25 31.3 3.72 33.5 3.96 35.7 4.21 40.0 4.73 44.4 5.27
12 22.6 2.84 27.0 3.30 31.3 3.78 33.5 4.03 35.7 4.28 40.0 4.81 44.4 5.36
14 22.6 2.88 27.0 3.34 31.3 3.83 33.5 4.09 35.7 4.35 40.0 4.89 44.4 5.46
16 22.6 2.92 27.0 3.39 31.3 3.90 33.5 4.16 35.7 4.42 40.0 4.98 44.4 5.56
18 22.6 2.96 27.0 3.45 31.3 3.96 33.5 4.23 35.7 4.50 40.0 5.07 44.4 5.66
20 22.6 3.00 27.0 3.50 31.3 4.03 33.5 4.30 35.7 4.58 40.0 5.16 44.4 5.77
21 22.6 3.03 27.0 3.53 31.3 4.06 33.5 4.34 35.7 4.62 40.0 5.21 44.4 5.82
23 22.6 3.07 27.0 3.58 31.3 4.13 33.5 4.41 35.7 4.71 40.0 5.31 44.4 5.95
25 22.6 3.12 27.0 3.64 31.3 4.20 33.5 4.51 35.7 4.85 40.0 5.57 44.4 6.35
27 22.6 3.17 27.0 3.77 31.3 4.44 33.5 4.79 35.7 5.16 40.0 5.93 44.4 6.77
29 22.6 3.35 27.0 4.00 31.3 4.71 33.5 5.09 35.7 5.48 40.0 6.31 44.4 7.21
31 22.6 3.54 27.0 4.23 31.3 4.99 33.5 5.40 35.7 5.82 40.0 6.71 44.4 7.7
33 22.6 3.74 27.0 4.48 31.3 5.29 33.5 5.72 35.7 6.17 40.0 7.13 44.4 8.2
35 22.6 3.95 27.0 4.74 31.3 5.60 33.5 6.06 35.7 6.54 40.0 7.6 44.4 8.7
37 22.6 4.16 27.0 5.00 31.3 5.93 33.5 6.42 35.7 6.94 40.0 8.0 44.4 9.2
39 22.6 4.39 27.0 5.29 31.3 6.27 33.5 6.80 35.7 7.4 40.0 8.5 44.4 9.8
