• Наружный блок • VRV
®
III с тепл. нас., комбинация с выс. знач. COP • RXYHQ-P9
• Системы VRV
®
• Наружный блок
16
5 Таблицы производительности
5 - 2 Таблицы холодопроизводительности
RXYHQ18P
4TW31462-3
NOTES - ANMERKUNGEN - ƴLjǍdžNJǟǔdžNJǓ - NOTAS - REMARQUES - NOTE - OPMERKINGEN - ȝȞȖȚȓȥȎțȖȭ - NOTLAR
1 The above table shows the average value of conditions which may occur.
Die obige Tabelle zeigt den Durchschnittswert der Bedingungen, die auftreten können.
ȈIJȠȞ ʌĮȡĮʌȐȞȦ ʌȓȞĮțĮ ĮȞĮȖȡȐijİIJĮȚ Ș ȝȑıȘ IJȚȝȒ ȖȚĮ ıȣȞșȒțİȢ ʌȠȣ ȝʌȠȡİȓ ȞĮ ʌȡȠțȪȥȠȣȞ.
La tabla de arriba muestra el valor medio de condiciones que pueden ocurrir.
Le tableau ci-dessus donne la valeur moyenne pour des conditions qui peuvent survenir.
La tabella in alto mostra il valore delle condizioni medie che si possono riscontrare.
De tabel hierboven geeft de gemiddelde waarde aan van situaties die kunnen voorvallen.
Ɍɚɛɥɢɰɚ ɪɚɫɩɨɥɨɠɟɧɧɚɹ ɜɵɲɟ ɩɨɤɚɡɵɜɚɟɬ ɫɪɟɞɧɟɟ ɡɧɚɱɟɧɢɟ ɭɫɥɨɜɢɣ, ɤɨɬɨɪɵɟ ɦɨɝɭɬ ɧɚɫɬɭɩɢɬɶ.
Yukarıdaki tablo meydana gelebilecek koúulların ortalama de÷erini göstermektedir.
TC: Total Capacity: kW ; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacity
index
Outdoor
air temp.
(°CDB)
Indoor air temperature: °CB
14.0 16.0 18.0 19.0 20.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130% 585.0 10 43.0 5.66 51.3 6.93 59.6 8.2 61.7 8.4 62.5 8.2 64.0 7.90 65.6 7.55
12 43.0 5.77 51.3 7.06 59.6 8.4 60.9 8.4 61.7 8.2 63.2 7.85 64.8 7.73
14 43.0 5.88 51.3 7.20 59.3 8.5 60.1 8.3 60.9 8.2 62.4 8.1 64.0 8.2
16 43.0 5.99 51.3 7.34 58.5 8.5 59.3 8.4 60.1 8.4 61.6 8.5 63.2 8.6
18 43.0 6.11 51.3 7.49 57.8 8.8 58.5 8.8 59.3 8.9 60.9 9.0 62.4 9.1
20 43.0 6.23 51.3 7.97 57.0 9.2 57.7 9.3 58.5 9.3 60.1 9.4 61.6 9.5
21 43.0 6.40 51.3 8.3 56.6 9.4 57.3 9.5 58.1 9.5 59.7 9.6 61.2 9.7
23 43.0 6.86 51.3 8.9 55.8 9.9 56.5 9.9 57.3 10.0 58.9 10.1 60.4 10.2
25 43.0 7.33 51.3 9.5 55.0 10.3 55.7 10.3 56.5 10.4 58.1 10.5 59.6 10.6
27 43.0 7.83 51.3 10.1 54.2 10.7 54.9 10.8 55.7 10.8 57.3 11.0 58.8 11.1
29 43.0 8.4 51.3 10.8 53.4 11.2 54.1 11.2 54.9 11.3 56.5 11.4 58.0 11.5
31 43.0 8.9 51.0 11.5 52.6 11.6 53.3 11.7 54.1 11.7 55.7 11.9 57.2 12.0
33 43.0 9.5 50.2 11.9 51.8 12.0 52.5 12.1 53.3 12.2 54.9 12.3 56.4 12.4
35 43.0 10.1 49.4 12.3 51.0 12.5 51.8 12.6 52.5 12.6 54.1 12.8 55.6 12.9
37 43.0 10.8 48.6 12.8 50.2 12.9 51.0 13.0 51.7 13.1 53.3 13.2 54.8 13.4
39 43.0 11.5 47.8 13.2 49.4 13.4 50.2 13.4 50.9 13.5 52.5 13.7 54.0 13.8
120% 540.0 10 39.7 5.17 47.3 6.32 55.0 7.52 58.8 8.1 61.5 8.5 62.9 8.1 64.4 7.82
12 39.7 5.27 47.3 6.44 55.0 7.66 58.8 8.3 60.7 8.4 62.1 8.1 63.6 7.77
14 39.7 5.37 47.3 6.56 55.0 7.81 58.8 8.4 59.9 8.4 61.4 8.1 62.8 8.1
16 39.7 5.47 47.3 6.69 55.0 7.96 58.4 8.5 59.1 8.4 60.6 8.5 62.0 8.5
18 39.7 5.58 47.3 6.82 55.0 8.2 57.6 8.8 58.3 8.8 59.8 8.9 61.2 9.0
20 39.7 5.69 47.3 7.09 55.0 8.8 56.8 9.2 57.5 9.3 59.0 9.3 60.4 9.4
21 39.7 5.74 47.3 7.35 55.0 9.2 56.4 9.4 57.1 9.5 58.6 9.6 60.0 9.6
23 39.7 6.13 47.3 7.87 54.9 9.8 55.6 9.9 56.3 9.9 57.8 10.0 59.2 10.1
25 39.7 6.55 47.3 8.4 54.1 10.2 54.8 10.3 55.5 10.3 57.0 10.4 58.4 10.5
27 39.7 7.00 47.3 9.0 53.3 10.7 54.0 10.7 54.7 10.8 56.2 10.9 57.6 11.0
29 39.7 7.46 47.3 9.6 52.5 11.1 53.2 11.2 53.9 11.2 55.4 11.3 56.8 11.4
31 39.7 7.95 47.3 10.3 51.7 11.5 52.4 11.6 53.1 11.6 54.6 11.8 56.0 11.9
33 39.7 8.5 47.3 10.9 50.9 12.0 51.6 12.0 52.3 12.1 53.8 12.2 55.2 12.3
35 39.7 9.0 47.3 11.7 50.1 12.4 50.8 12.5 51.6 12.5 53.0 12.7 54.4 12.8
37 39.7 9.6 47.3 12.4 49.3 12.8 50.0 12.9 50.8 13.0 52.2 13.1 53.6 13.3
39 39.7 10.2 47.1 13.1 48.5 13.3 49.2 13.4 50.0 13.4 51.4 13.6 52.8 13.7
110% 495.0 10 36.4 4.70 43.4 5.72 50.4 6.80 53.9 7.35 57.4 7.90 61.8 8.4 63.2 8.1
12 36.4 4.78 43.4 5.83 50.4 6.92 53.9 7.48 57.4 8.1 61.1 8.3 62.4 8.1
14 36.4 4.87 43.4 5.94 50.4 7.06 53.9 7.63 57.4 8.2 60.3 8.3 61.6 8.0
16 36.4 4.96 43.4 6.05 50.4 7.19 53.9 7.78 57.4 8.4 59.5 8.4 60.8 8.5
18 36.4 5.06 43.4 6.17 50.4 7.34 53.9 7.99 57.3 8.8 58.7 8.8 60.0 8.9
20 36.4 5.15 43.4 6.30 50.4 7.77 53.9 8.6 56.6 9.2 57.9 9.3 59.2 9.4
21 36.4 5.20 43.4 6.49 50.4 8.1 53.9 8.9 56.2 9.4 57.5 9.5 58.8 9.6
23 36.4 5.45 43.4 6.95 50.4 8.6 53.9 9.5 55.4 9.8 56.7 9.9 58.0 10.0
25 36.4 5.82 43.4 7.43 50.4 9.2 53.9 10.2 54.6 10.3 55.9 10.4 57.2 10.4
27 36.4 6.21 43.4 7.94 50.4 9.9 53.1 10.7 53.8 10.7 55.1 10.8 56.4 10.9
29 36.4 6.62 43.4 8.5 50.4 10.6 52.3 11.1 53.0 11.1 54.3 11.2 55.6 11.3
31 36.4 7.04 43.4 9.0 50.4 11.3 51.5 11.5 52.2 11.6 53.5 11.7 54.8 11.8
33 36.4 7.50 43.4 9.6 50.1 11.9 50.7 11.9 51.4 12.0 52.7 12.1 54.0 12.2
35 36.4 7.98 43.4 10.3 49.3 12.3 49.9 12.4 50.6 12.4 51.9 12.6 53.2 12.7
37 36.4 8.5 43.4 10.9 48.5 12.8 49.1 12.8 49.8 12.9 51.1 13.0 52.4 13.1
39 36.4 9.0 43.4 11.6 47.7 13.2 48.3 13.3 49.0 13.3 50.3 13.5 51.6 13.6
100% 450.0 10 33.1 4.24 39.4 5.14 45.8 6.09 49.0 6.58 52.2 7.08 58.6 8.1 61.9 8.4
12 33.1 4.31 39.4 5.23 45.8 6.20 49.0 6.70 52.2 7.21 58.6 8.2 61.1 8.3
14 33.1 4.39 39.4 5.33 45.8 6.32 49.0 6.83 52.2 7.35 58.6 8.4 60.4 8.3
16 33.1 4.47 39.4 5.43 45.8 6.44 49.0 6.96 52.2 7.49 58.4 8.5 59.6 8.4
18 33.1 4.55 39.4 5.54 45.8 6.57 49.0 7.10 52.2 7.64 57.6 8.8 58.8 8.8
20 33.1 4.64 39.4 5.65 45.8 6.77 49.0 7.46 52.2 8.2 56.8 9.2 58.0 9.3
21 33.1 4.68 39.4 5.70 45.8 7.01 49.0 7.73 52.2 8.5 56.4 9.4 57.6 9.5
23 33.1 4.81 39.4 6.08 45.8 7.51 49.0 8.3 52.2 9.1 55.6 9.9 56.8 9.9
25 33.1 5.13 39.4 6.50 45.8 8.03 49.0 8.9 52.2 9.7 54.8 10.3 56.0 10.4
27 33.1 5.47 39.4 6.94 45.8 8.6 49.0 9.5 52.2 10.4 54.0 10.7 55.2 10.8
29 33.1 5.82 39.4 7.40 45.8 9.2 49.0 10.1 52.0 11.1 53.2 11.2 54.4 11.2
31 33.1 6.19 39.4 7.88 45.8 9.8 49.0 10.8 51.2 11.5 52.4 11.6 53.6 11.7
33 33.1 6.59 39.4 8.4 45.8 10.4 49.0 11.5 50.4 11.9 51.6 12.0 52.8 12.1
35 33.1 7.00 39.4 8.9 45.8 11.1 49.0 12.3 49.6 12.4 50.8 12.5 52.0 12.6
37 33.1 7.44 39.4 9.5 45.8 11.8 48.2 12.7 48.8 12.8 50.0 12.9 51.2 13.0
39 33.1 7.90 39.4 10.1 45.8 12.6 47.4 13.2 48.0 13.2 49.2 13.4 50.4 13.5
W
9
