• Системы VRV
®
• Наружный блок
15
• Наружный блок • VRV
®
III с тепл. нас., комбинация с выс. знач. COP • RXYHQ-P9
5 Таблицы производительности
5 - 2 Таблицы холодопроизводительности
RXYHQ16P
4TW31462-3
TC: Total Capacity: kW ; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacity
index
Outdoor
air temp.
(°CDB)
Indoor air temperature: °CB
14.0 16.0 18.0 19.0 20.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90% 360.0 10 27.3 3.24 32.6 3.91 37.9 4.61 40.5 4.98 43.1 5.35 48.4 6.11 53.7 6.9
12 27.3 3.29 32.6 3.98 37.9 4.70 40.5 5.07 43.1 5.45 48.4 6.23 53.7 7.0
14 27.3 3.35 32.6 4.05 37.9 4.78 40.5 5.17 43.1 5.55 48.4 6.34 53.7 7.2
16 27.3 3.41 32.6 4.12 37.9 4.88 40.5 5.26 43.1 5.66 48.4 6.47 53.6 7.3
18 27.3 3.47 32.6 4.20 37.9 4.97 40.5 5.37 43.1 5.77 48.4 6.6 52.8 7.5
20 27.3 3.53 32.6 4.28 37.9 5.07 40.5 5.48 43.1 5.99 48.4 7.1 52.1 7.9
21 27.3 3.57 32.6 4.32 37.9 5.16 40.5 5.67 43.1 6.20 48.4 7.3 51.7 8.0
23 27.3 3.64 32.6 4.50 37.9 5.52 40.5 6.07 43.1 6.6 48.4 7.9 51.0 8.4
25 27.3 3.83 32.6 4.81 37.9 5.90 40.5 6.49 43.1 7.1 48.4 8.4 50.3 8.8
27 27.3 4.08 32.6 5.13 37.9 6.30 40.5 6.9 43.1 7.6 48.4 9.0 49.6 9.1
29 27.3 4.34 32.6 5.46 37.9 6.7 40.5 7.4 43.1 8.1 47.8 9.4 48.8 9.5
31 27.3 4.61 32.6 5.82 37.9 7.2 40.5 7.9 43.1 8.7 47.1 9.8 48.1 9.9
33 27.3 4.90 32.6 6.19 37.9 7.6 40.5 8.4 43.1 9.2 46.4 10.2 47.4 10.3
35 27.3 5.20 32.6 6.6 37.9 8.1 40.5 9.0 43.1 9.9 45.6 10.6 46.6 10.6
37 27.3 5.52 32.6 7.0 37.9 8.7 40.5 9.6 43.1 10.5 44.9 10.9 45.9 11.0
39 27.3 5.86 32.6 7.4 37.9 9.2 40.5 10.2 43.1 11.2 44.2 11.3 45.2 11.4
80% 320.0 10 24.3 2.87 29.0 3.44 33.7 4.04 36.0 4.36 38.3 4.68 43.0 5.33 47.7 6.01
12 24.3 2.92 29.0 3.50 33.7 4.12 36.0 4.44 38.3 4.76 43.0 5.43 47.7 6.12
14 24.3 2.97 29.0 3.56 33.7 4.19 36.0 4.52 38.3 4.85 43.0 5.54 47.7 6.24
16 24.3 3.02 29.0 3.63 33.7 4.27 36.0 4.60 38.3 4.95 43.0 5.64 47.7 6.36
18 24.3 3.07 29.0 3.69 33.7 4.35 36.0 4.69 38.3 5.04 43.0 5.76 47.7 6.49
20 24.3 3.13 29.0 3.76 33.7 4.44 36.0 4.79 38.3 5.14 43.0 5.97 47.7 6.9
21 24.3 3.15 29.0 3.80 33.7 4.48 36.0 4.83 38.3 5.25 43.0 6.18 47.7 7.2
23 24.3 3.21 29.0 3.87 33.7 4.70 36.0 5.15 38.3 5.62 43.0 6.6 47.7 7.7
25 24.3 3.32 29.0 4.12 33.7 5.02 36.0 5.50 38.3 6.00 43.0 7.1 47.7 8.3
27 24.3 3.53 29.0 4.39 33.7 5.35 36.0 5.87 38.3 6.41 43.0 7.6 47.7 8.8
29 24.3 3.75 29.0 4.67 33.7 5.71 36.0 6.26 38.3 6.8 43.0 8.1 47.7 9.4
31 24.3 3.98 29.0 4.97 33.7 6.08 36.0 6.7 38.3 7.3 43.0 8.6 47.0 9.8
33 24.3 4.22 29.0 5.28 33.7 6.47 36.0 7.1 38.3 7.8 43.0 9.2 46.2 10.2
35 24.3 4.48 29.0 5.61 33.7 6.9 36.0 7.6 38.3 8.3 43.0 9.8 45.5 10.5
37 24.3 4.75 29.0 5.96 33.7 7.3 36.0 8.0 38.3 8.8 43.0 10.5 44.8 10.9
39 24.3 5.03 29.0 6.33 33.7 7.8 36.0 8.6 38.3 9.4 43.0 11.1 44.0 11.3
70% 280.0 10 21.3 2.53 25.4 3.00 29.5 3.50 31.5 3.76 33.5 4.03 37.6 4.58 41.7 5.15
12 21.3 2.57 25.4 3.05 29.5 3.56 31.5 3.83 33.5 4.10 37.6 4.67 41.7 5.25
14 21.3 2.61 25.4 3.10 29.5 3.63 31.5 3.90 33.5 4.18 37.6 4.75 41.7 5.35
16 21.3 2.65 25.4 3.15 29.5 3.69 31.5 3.97 33.5 4.26 37.6 4.84 41.7 5.45
18 21.3 2.69 25.4 3.21 29.5 3.76 31.5 4.04 33.5 4.34 37.6 4.94 41.7 5.56
20 21.3 2.74 25.4 3.27 29.5 3.83 31.5 4.12 33.5 4.42 37.6 5.04 41.7 5.71
21 21.3 2.76 25.4 3.30 29.5 3.87 31.5 4.16 33.5 4.46 37.6 5.12 41.7 5.92
23 21.3 2.81 25.4 3.36 29.5 3.95 31.5 4.30 33.5 4.68 37.6 5.47 41.7 6.34
25 21.3 2.86 25.4 3.49 29.5 4.21 31.5 4.59 33.5 5.00 37.6 5.85 41.7 6.8
27 21.3 3.02 25.4 3.72 29.5 4.48 31.5 4.90 33.5 5.33 37.6 6.25 41.7 7.2
29 21.3 3.21 25.4 3.95 29.5 4.77 31.5 5.22 33.5 5.68 37.6 6.7 41.7 7.7
31 21.3 3.40 25.4 4.20 29.5 5.08 31.5 5.55 33.5 6.05 37.6 7.1 41.7 8.3
33 21.3 3.60 25.4 4.45 29.5 5.40 31.5 5.91 33.5 6.44 37.6 7.6 41.7 8.8
35 21.3 3.82 25.4 4.73 29.5 5.74 31.5 6.28 33.5 6.8 37.6 8.1 41.7 9.4
37 21.3 4.04 25.4 5.01 29.5 6.09 31.5 6.7 33.5 7.3 37.6 8.6 41.7 10.0
39 21.3 4.27 25.4 5.31 29.5 6.47 31.5 7.1 33.5 7.7 37.6 9.1 41.7 10.6
60% 240.0 10 18.2 2.20 21.7 2.58 25.2 2.99 27.0 3.20 28.8 3.41 32.3 3.86 35.8 4.33
12 18.2 2.23 21.7 2.62 25.2 3.04 27.0 3.25 28.8 3.47 32.3 3.93 35.8 4.41
14 18.2 2.26 21.7 2.66 25.2 3.09 27.0 3.31 28.8 3.53 32.3 4.00 35.8 4.49
16 18.2 2.30 21.7 2.71 25.2 3.14 27.0 3.37 28.8 3.60 32.3 4.08 35.8 4.57
18 18.2 2.33 21.7 2.75 25.2 3.19 27.0 3.43 28.8 3.66 32.3 4.15 35.8 4.66
20 18.2 2.37 21.7 2.80 25.2 3.25 27.0 3.49 28.8 3.73 32.3 4.23 35.8 4.75
21 18.2 2.39 21.7 2.82 25.2 3.28 27.0 3.52 28.8 3.77 32.3 4.27 35.8 4.80
23 18.2 2.43 21.7 2.87 25.2 3.34 27.0 3.59 28.8 3.84 32.3 4.44 35.8 5.10
25 18.2 2.47 21.7 2.92 25.2 3.47 27.0 3.77 28.8 4.08 32.3 4.74 35.8 5.45
27 18.2 2.56 21.7 3.10 25.2 3.70 27.0 4.02 28.8 4.35 32.3 5.06 35.8 5.82
29 18.2 2.71 21.7 3.29 25.2 3.93 27.0 4.27 28.8 4.63 32.3 5.39 35.8 6.21
31 18.2 2.87 21.7 3.49 25.2 4.17 27.0 4.54 28.8 4.92 32.3 5.74 35.8 6.6
33 18.2 3.03 21.7 3.70 25.2 4.43 27.0 4.82 28.8 5.23 32.3 6.10 35.8 7.0
35 18.2 3.21 21.7 3.92 25.2 4.70 27.0 5.12 28.8 5.56 32.3 6.49 35.8 7.5
37 18.2 3.39 21.7 4.15 25.2 4.98 27.0 5.43 28.8 5.90 32.3 6.9 35.8 8.0
39 18.2 3.58 21.7 4.39 25.2 5.28 27.0 5.76 28.8 6.26 32.3 7.3 35.8 8.5
50% 200.0 10 15.2 1.89 18.1 2.19 21.0 2.50 22.5 2.67 24.0 2.84 26.9 3.18 29.8 3.55
12 15.2 1.91 18.1 2.22 21.0 2.54 22.5 2.71 24.0 2.88 26.9 3.24 29.8 3.61
14 15.2 1.94 18.1 2.25 21.0 2.58 22.5 2.75 24.0 2.93 26.9 3.29 29.8 3.67
16 15.2 1.97 18.1 2.28 21.0 2.62 22.5 2.80 24.0 2.98 26.9 3.35 29.8 3.74
18 15.2 1.99 18.1 2.32 21.0 2.66 22.5 2.84 24.0 3.03 26.9 3.41 29.8 3.81
20 15.2 2.02 18.1 2.36 21.0 2.71 22.5 2.89 24.0 3.08 26.9 3.47 29.8 3.88
21 15.2 2.04 18.1 2.37 21.0 2.73 22.5 2.92 24.0 3.11 26.9 3.51 29.8 3.92
23 15.2 2.07 18.1 2.41 21.0 2.78 22.5 2.97 24.0 3.17 26.9 3.57 29.8 4.01
25 15.2 2.10 18.1 2.45 21.0 2.83 22.5 3.03 24.0 3.26 26.9 3.75 29.8 4.28
27 15.2 2.13 18.1 2.54 21.0 2.99 22.5 3.22 24.0 3.47 26.9 3.99 29.8 4.56
29 15.2 2.26 18.1 2.69 21.0 3.17 22.5 3.42 24.0 3.69 26.9 4.25 29.8 4.85
31 15.2 2.38 18.1 2.85 21.0 3.36 22.5 3.63 24.0 3.92 26.9 4.52 29.8 5.16
33 15.2 2.52 18.1 3.01 21.0 3.56 22.5 3.85 24.0 4.15 26.9 4.80 29.8 5.49
35 15.2 2.66 18.1 3.19 21.0 3.77 22.5 4.08 24.0 4.41 26.9 5.09 29.8 5.83
37 15.2 2.80 18.1 3.37 21.0 3.99 22.5 4.32 24.0 4.67 26.9 5.40 29.8 6.19
39 15.2 2.95 18.1 3.56 21.0 4.22 22.5 4.58 24.0 4.95 26.9 5.73 29.8 6.6
