• Системы VRV
®
• Наружный блок
19
• Наружный блок • VRV
®
III с тепл. нас., комбинация с выс. знач. COP • RXYHQ-P9
5 Таблицы производительности
5 - 2 Таблицы холодопроизводительности
RXYHQ20P
4TW31462-3
TC: Total Capacity: kW ; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacity
index
Outdoor
air temp.
(°CDB)
Indoor air temperature: °CB
14.0 16.0 18.0 19.0 20.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90% 450.0 10 34.0 4.26 40.5 5.13 47.0 6.06 50.3 6.54 53.6 7.03 60.1 8.03 66.7 9.1
12 34.0 4.33 40.5 5.22 47.0 6.17 50.3 6.66 53.6 7.16 60.1 8.18 66.7 9.2
14 34.0 4.40 40.5 5.32 47.0 6.29 50.3 6.79 53.6 7.30 60.1 8.34 66.7 9.4
16 34.0 4.48 40.5 5.42 47.0 6.41 50.3 6.92 53.6 7.44 60.1 8.50 66.6 9.6
18 34.0 4.56 40.5 5.52 47.0 6.53 50.3 7.06 53.6 7.59 60.1 8.7 65.6 9.9
20 34.0 4.65 40.5 5.63 47.0 6.66 50.3 7.20 53.6 7.87 60.1 9.3 64.7 10.3
21 34.0 4.69 40.5 5.68 47.0 6.78 50.3 7.45 53.6 8.15 60.1 9.7 64.3 10.6
23 34.0 4.78 40.5 5.92 47.0 7.25 50.3 7.98 53.6 8.7 60.1 10.4 63.4 11.1
25 34.0 5.03 40.5 6.32 47.0 7.75 50.3 8.53 53.6 9.3 60.1 11.1 62.5 11.5
27 34.0 5.36 40.5 6.74 47.0 8.28 50.3 9.1 53.6 10.0 60.1 11.9 61.6 12.0
29 34.0 5.70 40.5 7.18 47.0 8.8 50.3 9.7 53.6 10.7 59.4 12.4 60.6 12.5
31 34.0 6.06 40.5 7.64 47.0 9.4 50.3 10.4 53.6 11.4 58.5 12.9 59.7 13.0
33 34.0 6.44 40.5 8.13 47.0 10.0 50.3 11.1 53.6 12.1 57.6 13.4 58.8 13.5
35 34.0 6.84 40.5 8.7 47.0 10.7 50.3 11.8 53.6 12.9 56.7 13.9 57.9 14.0
37 34.0 7.25 40.5 9.2 47.0 11.4 50.3 12.6 53.6 13.8 55.8 14.4 57.0 14.5
39 34.0 7.70 40.5 9.8 47.0 12.1 50.3 13.4 53.6 14.7 54.9 14.9 56.1 15.0
80% 400.0 10 30.2 3.78 36.0 4.52 41.8 5.32 44.7 5.73 47.6 6.15 53.4 7.01 59.3 7.90
12 30.2 3.84 36.0 4.60 41.8 5.41 44.7 5.83 47.6 6.26 53.4 7.14 59.3 8.05
14 30.2 3.90 36.0 4.68 41.8 5.51 44.7 5.94 47.6 6.38 53.4 7.28 59.3 8.20
16 30.2 3.97 36.0 4.77 41.8 5.61 44.7 6.05 47.6 6.50 53.4 7.42 59.3 8.36
18 30.2 4.04 36.0 4.85 41.8 5.72 44.7 6.17 47.6 6.63 53.4 7.56 59.3 8.53
20 30.2 4.11 36.0 4.95 41.8 5.83 44.7 6.29 47.6 6.76 53.4 7.84 59.3 9.1
21 30.2 4.15 36.0 4.99 41.8 5.89 44.7 6.35 47.6 6.90 53.4 8.12 59.3 9.4
23 30.2 4.22 36.0 5.09 41.8 6.17 44.7 6.76 47.6 7.38 53.4 8.7 59.3 10.1
25 30.2 4.36 36.0 5.42 41.8 6.59 44.7 7.23 47.6 7.89 53.4 9.3 59.3 10.8
27 30.2 4.64 36.0 5.77 41.8 7.04 44.7 7.72 47.6 8.43 53.4 10.0 59.3 11.6
29 30.2 4.93 36.0 6.14 41.8 7.50 44.7 8.23 47.6 9.0 53.4 10.6 59.3 12.4
31 30.2 5.23 36.0 6.53 41.8 7.99 44.7 8.8 47.6 9.6 53.4 11.3 58.3 12.9
33 30.2 5.55 36.0 6.95 41.8 8.50 44.7 9.3 47.6 10.2 53.4 12.1 57.4 13.4
35 30.2 5.89 36.0 7.38 41.8 9.0 44.7 9.9 47.6 10.9 53.4 12.9 56.5 13.9
37 30.2 6.24 36.0 7.84 41.8 9.6 44.7 10.6 47.6 11.6 53.4 13.7 55.6 14.3
39 30.2 6.61 36.0 8.32 41.8 10.2 44.7 11.3 47.6 12.3 53.4 14.6 54.7 14.8
70% 350.0 10 26.4 3.32 31.5 3.94 36.6 4.60 39.1 4.95 41.7 5.30 46.8 6.02 51.9 6.77
12 26.4 3.37 31.5 4.01 36.6 4.68 39.1 5.03 41.7 5.39 46.8 6.13 51.9 6.90
14 26.4 3.43 31.5 4.07 36.6 4.76 39.1 5.12 41.7 5.49 46.8 6.25 51.9 7.03
16 26.4 3.48 31.5 4.14 36.6 4.85 39.1 5.22 41.7 5.59 46.8 6.37 51.9 7.16
18 26.4 3.54 31.5 4.22 36.6 4.94 39.1 5.32 41.7 5.70 46.8 6.49 51.9 7.31
20 26.4 3.60 31.5 4.29 36.6 5.03 39.1 5.42 41.7 5.81 46.8 6.62 51.9 7.51
21 26.4 3.63 31.5 4.33 36.6 5.08 39.1 5.47 41.7 5.87 46.8 6.72 51.9 7.78
23 26.4 3.69 31.5 4.41 36.6 5.19 39.1 5.66 41.7 6.15 46.8 7.20 51.9 8.33
25 26.4 3.76 31.5 4.59 36.6 5.53 39.1 6.04 41.7 6.57 46.8 7.69 51.9 8.9
27 26.4 3.97 31.5 4.88 36.6 5.89 39.1 6.44 41.7 7.00 46.8 8.21 51.9 9.5
29 26.4 4.21 31.5 5.19 36.6 6.27 39.1 6.86 41.7 7.46 46.8 8.8 51.9 10.2
31 26.4 4.47 31.5 5.51 36.6 6.67 39.1 7.30 41.7 7.95 46.8 9.3 51.9 10.8
33 26.4 4.74 31.5 5.85 36.6 7.10 39.1 7.76 41.7 8.46 46.8 10.0 51.9 11.6
35 26.4 5.02 31.5 6.21 36.6 7.54 39.1 8.25 41.7 9.0 46.8 10.6 51.9 12.3
37 26.4 5.31 31.5 6.59 36.6 8.01 39.1 8.8 41.7 9.6 46.8 11.3 51.9 13.1
39 26.4 5.62 31.5 6.98 36.6 8.50 39.1 9.3 41.7 10.2 46.8 12.0 51.9 14.0
60% 300.0 10 22.6 2.89 27.0 3.39 31.4 3.93 33.5 4.20 35.7 4.49 40.1 5.08 44.4 5.69
12 22.6 2.93 27.0 3.44 31.4 3.99 33.5 4.27 35.7 4.56 40.1 5.17 44.4 5.79
14 22.6 2.97 27.0 3.50 31.4 4.06 33.5 4.35 35.7 4.64 40.1 5.26 44.4 5.90
16 22.6 3.02 27.0 3.56 31.4 4.13 33.5 4.42 35.7 4.73 40.1 5.36 44.4 6.01
18 22.6 3.06 27.0 3.61 31.4 4.20 33.5 4.50 35.7 4.81 40.1 5.46 44.4 6.13
20 22.6 3.11 27.0 3.68 31.4 4.27 33.5 4.59 35.7 4.90 40.1 5.56 44.4 6.25
21 22.6 3.14 27.0 3.71 31.4 4.31 33.5 4.63 35.7 4.95 40.1 5.62 44.4 6.31
23 22.6 3.19 27.0 3.77 31.4 4.39 33.5 4.72 35.7 5.05 40.1 5.84 44.4 6.71
25 22.6 3.24 27.0 3.84 31.4 4.56 33.5 4.96 35.7 5.36 40.1 6.23 44.4 7.17
27 22.6 3.36 27.0 4.07 31.4 4.86 33.5 5.28 35.7 5.71 40.1 6.65 44.4 7.65
29 22.6 3.56 27.0 4.32 31.4 5.16 33.5 5.61 35.7 6.08 40.1 7.08 44.4 8.16
31 22.6 3.77 27.0 4.58 31.4 5.48 33.5 5.97 35.7 6.47 40.1 7.54 44.4 8.7
33 22.6 3.99 27.0 4.86 31.4 5.82 33.5 6.34 35.7 6.88 40.1 8.02 44.4 9.3
35 22.6 4.22 27.0 5.15 31.4 6.18 33.5 6.73 35.7 7.30 40.1 8.53 44.4 9.9
37 22.6 4.46 27.0 5.45 31.4 6.55 33.5 7.14 35.7 7.76 40.1 9.1 44.4 10.5
39 22.6 4.71 27.0 5.77 31.4 6.94 33.5 7.57 35.7 8.23 40.1 9.6 44.4 11.2
50% 250.0 10 18.9 2.48 22.5 2.87 26.1 3.29 28.0 3.51 29.8 3.73 33.4 4.19 37.0 4.66
12 18.9 2.52 22.5 2.92 26.1 3.34 28.0 3.56 29.8 3.79 33.4 4.26 37.0 4.74
14 18.9 2.55 22.5 2.96 26.1 3.39 28.0 3.62 29.8 3.85 33.4 4.33 37.0 4.83
16 18.9 2.58 22.5 3.00 26.1 3.45 28.0 3.68 29.8 3.91 33.4 4.40 37.0 4.92
18 18.9 2.62 22.5 3.05 26.1 3.50 28.0 3.74 29.8 3.98 33.4 4.48 37.0 5.01
20 18.9 2.66 22.5 3.10 26.1 3.56 28.0 3.80 29.8 4.05 33.4 4.57 37.0 5.10
21 18.9 2.68 22.5 3.12 26.1 3.59 28.0 3.84 29.8 4.09 33.4 4.61 37.0 5.15
23 18.9 2.72 22.5 3.17 26.1 3.65 28.0 3.91 29.8 4.16 33.4 4.70 37.0 5.27
25 18.9 2.76 22.5 3.22 26.1 3.72 28.0 3.99 29.8 4.29 33.4 4.93 37.0 5.62
27 18.9 2.80 22.5 3.34 26.1 3.92 28.0 4.24 29.8 4.56 33.4 5.25 37.0 5.99
29 18.9 2.96 22.5 3.54 26.1 4.17 28.0 4.50 29.8 4.85 33.4 5.58 37.0 6.38
31 18.9 3.13 22.5 3.74 26.1 4.42 28.0 4.77 29.8 5.15 33.4 5.94 37.0 6.78
33 18.9 3.31 22.5 3.96 26.1 4.68 28.0 5.06 29.8 5.46 33.4 6.30 37.0 7.21
35 18.9 3.49 22.5 4.19 26.1 4.95 28.0 5.36 29.8 5.79 33.4 6.69 37.0 7.66
37 18.9 3.68 22.5 4.43 26.1 5.24 28.0 5.68 29.8 6.14 33.4 7.10 37.0 8.14
39 18.9 3.88 22.5 4.68 26.1 5.55 28.0 6.02 29.8 6.50 33.4 7.53 37.0 8.6
