• Системы VRV
®
• Наружный блок
17
• Наружный блок • VRV
®
III с тепл. нас., комбинация с выс. знач. COP • RXYHQ-P9
5 Таблицы производительности
5 - 2 Таблицы холодопроизводительности
RXYHQ18P
4TW31462-3
TC: Total Capacity: kW ; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacity
index
Outdoor
air temp.
(°CDB)
Indoor air temperature: °CB
14.0 16.0 18.0 19.0 20.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90% 405.0 10 29.8 3.79 35.5 4.58 41.2 5.40 44.1 5.83 47.0 6.27 52.7 7.16 58.4 8.1
12 29.8 3.86 35.5 4.66 41.2 5.50 44.1 5.94 47.0 6.38 52.7 7.29 58.4 8.2
14 29.8 3.92 35.5 4.74 41.2 5.60 44.1 6.05 47.0 6.50 52.7 7.43 58.4 8.4
16 29.8 3.99 35.5 4.83 41.2 5.71 44.1 6.17 47.0 6.63 52.7 7.58 58.3 8.5
18 29.8 4.07 35.5 4.92 41.2 5.82 44.1 6.29 47.0 6.76 52.7 7.73 57.5 8.8
20 29.8 4.14 35.5 5.02 41.2 5.94 44.1 6.41 47.0 7.01 52.7 8.3 56.7 9.2
21 29.8 4.18 35.5 5.06 41.2 6.04 44.1 6.64 47.0 7.26 52.7 8.6 56.3 9.4
23 29.8 4.26 35.5 5.27 41.2 6.47 44.1 7.11 47.0 7.78 52.7 9.2 55.5 9.9
25 29.8 4.49 35.5 5.63 41.2 6.91 44.1 7.60 47.0 8.3 52.7 9.9 54.8 10.3
27 29.8 4.78 35.5 6.01 41.2 7.38 44.1 8.1 47.0 8.9 52.7 10.6 54.0 10.7
29 29.8 5.08 35.5 6.40 41.2 7.88 44.1 8.7 47.0 9.5 52.1 11.1 53.2 11.1
31 29.8 5.40 35.5 6.81 41.2 8.4 44.1 9.3 47.0 10.1 51.3 11.5 52.4 11.6
33 29.8 5.74 35.5 7.25 41.2 8.9 44.1 9.9 47.0 10.8 50.5 11.9 51.6 12.0
35 29.8 6.09 35.5 7.71 41.2 9.5 44.1 10.5 47.0 11.5 49.7 12.4 50.8 12.5
37 29.8 6.47 35.5 8.2 41.2 10.1 44.1 11.2 47.0 12.3 48.9 12.8 50.0 12.9
39 29.8 6.86 35.5 8.7 41.2 10.8 44.1 11.9 47.0 13.1 48.1 13.2 49.2 13.3
80% 360.0 10 26.5 3.37 31.6 4.03 36.7 4.74 39.2 5.10 41.7 5.48 46.8 6.25 51.9 7.04
12 26.5 3.42 31.6 4.10 36.7 4.82 39.2 5.20 41.7 5.58 46.8 6.36 51.9 7.17
14 26.5 3.48 31.6 4.17 36.7 4.91 39.2 5.29 41.7 5.68 46.8 6.49 51.9 7.31
16 26.5 3.54 31.6 4.25 36.7 5.00 39.2 5.39 41.7 5.79 46.8 6.61 51.9 7.45
18 26.5 3.60 31.6 4.33 36.7 5.10 39.2 5.50 41.7 5.91 46.8 6.74 51.9 7.60
20 26.5 3.66 31.6 4.41 36.7 5.20 39.2 5.61 41.7 6.02 46.8 6.99 51.9 8.1
21 26.5 3.70 31.6 4.45 36.7 5.25 39.2 5.66 41.7 6.15 46.8 7.24 51.9 8.4
23 26.5 3.76 31.6 4.54 36.7 5.50 39.2 6.03 41.7 6.58 46.8 7.75 51.9 9.0
25 26.5 3.89 31.6 4.83 36.7 5.88 39.2 6.44 41.7 7.03 46.8 8.3 51.9 9.7
27 26.5 4.13 31.6 5.14 36.7 6.27 39.2 6.88 41.7 7.51 46.8 8.9 51.9 10.3
29 26.5 4.39 31.6 5.48 36.7 6.68 39.2 7.33 41.7 8.02 46.8 9.5 51.9 11.1
31 26.5 4.66 31.6 5.82 36.7 7.12 39.2 7.82 41.7 8.5 46.8 10.1 51.1 11.5
33 26.5 4.95 31.6 6.19 36.7 7.58 39.2 8.3 41.7 9.1 46.8 10.8 50.3 11.9
35 26.5 5.25 31.6 6.58 36.7 8.1 39.2 8.9 41.7 9.7 46.8 11.5 49.6 12.4
37 26.5 5.56 31.6 6.98 36.7 8.6 39.2 9.4 41.7 10.3 46.8 12.3 48.8 12.8
39 26.5 5.90 31.6 7.41 36.7 9.1 39.2 10.0 41.7 11.0 46.8 13.1 48.0 13.2
70% 315.0 10 23.1 2.96 27.6 3.51 32.1 4.10 34.3 4.41 36.5 4.72 41.0 5.37 45.5 6.03
12 23.1 3.01 27.6 3.57 32.1 4.17 34.3 4.49 36.5 4.81 41.0 5.47 45.5 6.15
14 23.1 3.05 27.6 3.63 32.1 4.25 34.3 4.57 36.5 4.89 41.0 5.57 45.5 6.26
16 23.1 3.10 27.6 3.69 32.1 4.32 34.3 4.65 36.5 4.98 41.0 5.67 45.5 6.39
18 23.1 3.15 27.6 3.76 32.1 4.40 34.3 4.74 36.5 5.08 41.0 5.78 45.5 6.51
20 23.1 3.21 27.6 3.83 32.1 4.49 34.3 4.83 36.5 5.18 41.0 5.90 45.5 6.69
21 23.1 3.23 27.6 3.86 32.1 4.53 34.3 4.88 36.5 5.23 41.0 5.99 45.5 6.93
23 23.1 3.29 27.6 3.93 32.1 4.62 34.3 5.04 36.5 5.48 41.0 6.41 45.5 7.42
25 23.1 3.35 27.6 4.09 32.1 4.93 34.3 5.38 36.5 5.85 41.0 6.86 45.5 7.94
27 23.1 3.54 27.6 4.35 32.1 5.25 34.3 5.74 36.5 6.24 41.0 7.32 45.5 8.5
29 23.1 3.76 27.6 4.63 32.1 5.59 34.3 6.11 36.5 6.65 41.0 7.81 45.5 9.1
31 23.1 3.98 27.6 4.91 32.1 5.95 34.3 6.50 36.5 7.09 41.0 8.3 45.5 9.7
33 23.1 4.22 27.6 5.22 32.1 6.32 34.3 6.92 36.5 7.54 41.0 8.9 45.5 10.3
35 23.1 4.47 27.6 5.54 32.1 6.72 34.3 7.36 36.5 8.02 41.0 9.4 45.5 11.0
37 23.1 4.73 27.6 5.87 32.1 7.14 34.3 7.82 36.5 8.5 41.0 10.1 45.5 11.7
39 23.1 5.01 27.6 6.22 32.1 7.58 34.3 8.3 36.5 9.1 41.0 10.7 45.5 12.5
60% 270.0 10 19.8 2.58 23.7 3.02 27.5 3.50 29.4 3.75 31.3 4.00 35.1 4.52 39.0 5.07
12 19.8 2.61 23.7 3.07 27.5 3.56 29.4 3.81 31.3 4.07 35.1 4.60 39.0 5.16
14 19.8 2.65 23.7 3.12 27.5 3.62 29.4 3.87 31.3 4.14 35.1 4.69 39.0 5.26
16 19.8 2.69 23.7 3.17 27.5 3.68 29.4 3.94 31.3 4.21 35.1 4.77 39.0 5.36
18 19.8 2.73 23.7 3.22 27.5 3.74 29.4 4.01 31.3 4.29 35.1 4.86 39.0 5.46
20 19.8 2.77 23.7 3.28 27.5 3.81 29.4 4.09 31.3 4.37 35.1 4.96 39.0 5.57
21 19.8 2.80 23.7 3.30 27.5 3.84 29.4 4.13 31.3 4.41 35.1 5.01 39.0 5.62
23 19.8 2.84 23.7 3.36 27.5 3.92 29.4 4.20 31.3 4.50 35.1 5.20 39.0 5.98
25 19.8 2.89 23.7 3.42 27.5 4.07 29.4 4.42 31.3 4.78 35.1 5.55 39.0 6.39
27 19.8 2.99 23.7 3.63 27.5 4.33 29.4 4.70 31.3 5.09 35.1 5.92 39.0 6.82
29 19.8 3.17 23.7 3.85 27.5 4.60 29.4 5.00 31.3 5.42 35.1 6.31 39.0 7.27
31 19.8 3.36 23.7 4.09 27.5 4.89 29.4 5.32 31.3 5.77 35.1 6.72 39.0 7.75
33 19.8 3.55 23.7 4.33 27.5 5.19 29.4 5.65 31.3 6.13 35.1 7.15 39.0 8.3
35 19.8 3.76 23.7 4.59 27.5 5.51 29.4 6.00 31.3 6.51 35.1 7.60 39.0 8.8
37 19.8 3.97 23.7 4.86 27.5 5.84 29.4 6.36 31.3 6.91 35.1 8.1 39.0 9.3
39 19.8 4.20 23.7 5.14 27.5 6.19 29.4 6.75 31.3 7.34 35.1 8.6 39.0 9.9
50% 225.0 10 16.5 2.21 19.7 2.56 22.9 2.93 24.5 3.12 26.1 3.32 29.3 3.73 32.5 4.16
12 16.5 2.24 19.7 2.60 22.9 2.98 24.5 3.17 26.1 3.38 29.3 3.79 32.5 4.23
14 16.5 2.27 19.7 2.64 22.9 3.02 24.5 3.22 26.1 3.43 29.3 3.86 32.5 4.30
16 16.5 2.30 19.7 2.68 22.9 3.07 24.5 3.28 26.1 3.49 29.3 3.93 32.5 4.38
18 16.5 2.34 19.7 2.72 22.9 3.12 24.5 3.33 26.1 3.55 29.3 4.00 32.5 4.46
20 16.5 2.37 19.7 2.76 22.9 3.17 24.5 3.39 26.1 3.61 29.3 4.07 32.5 4.55
21 16.5 2.39 19.7 2.78 22.9 3.20 24.5 3.42 26.1 3.64 29.3 4.11 32.5 4.59
23 16.5 2.42 19.7 2.83 22.9 3.26 24.5 3.48 26.1 3.71 29.3 4.19 32.5 4.69
25 16.5 2.46 19.7 2.87 22.9 3.31 24.5 3.55 26.1 3.82 29.3 4.39 32.5 5.01
27 16.5 2.50 19.7 2.98 22.9 3.50 24.5 3.78 26.1 4.07 29.3 4.68 32.5 5.34
29 16.5 2.64 19.7 3.15 22.9 3.71 24.5 4.01 26.1 4.32 29.3 4.98 32.5 5.68
31 16.5 2.79 19.7 3.34 22.9 3.94 24.5 4.25 26.1 4.59 29.3 5.29 32.5 6.05
33 16.5 2.95 19.7 3.53 22.9 4.17 24.5 4.51 26.1 4.87 29.3 5.62 32.5 6.43
35 16.5 3.11 19.7 3.73 22.9 4.42 24.5 4.78 26.1 5.16 29.3 5.96 32.5 6.83
37 16.5 3.28 19.7 3.95 22.9 4.67 24.5 5.06 26.1 5.47 29.3 6.33 32.5 7.26
39 16.5 3.46 19.7 4.17 22.9 4.95 24.5 5.36 26.1 5.79 29.3 6.71 32.5 7.70
