• Наружный блок • VRV
®
III с тепл. нас., комбинация с выс. знач. COP • RXYHQ-P9
• Системы VRV
®
• Наружный блок
30
5 Таблицы производительности
5 - 2 Таблицы холодопроизводительности
RXYHQ32P
4TW31462-3
NOTES - ANMERKUNGEN - ƴLjǍdžNJǟǔdžNJǓ - NOTAS - REMARQUES - NOTE - OPMERKINGEN - ȝȞȖȚȓȥȎțȖȭ - NOTLAR
1 The above table shows the average value of conditions which may occur.
Die obige Tabelle zeigt den Durchschnittswert der Bedingungen, die auftreten können.
ȈIJȠȞ ʌĮȡĮʌȐȞȦ ʌȓȞĮțĮ ĮȞĮȖȡȐijİIJĮȚ Ș ȝȑıȘ IJȚȝȒ ȖȚĮ ıȣȞșȒțİȢ ʌȠȣ ȝʌȠȡİȓ ȞĮ ʌȡȠțȪȥȠȣȞ.
La tabla de arriba muestra el valor medio de condiciones que pueden ocurrir.
Le tableau ci-dessus donne la valeur moyenne pour des conditions qui peuvent survenir.
La tabella in alto mostra il valore delle condizioni medie che si possono riscontrare.
De tabel hierboven geeft de gemiddelde waarde aan van situaties die kunnen voorvallen.
Ɍɚɛɥɢɰɚ ɪɚɫɩɨɥɨɠɟɧɧɚɹ ɜɵɲɟ ɩɨɤɚɡɵɜɚɟɬ ɫɪɟɞɧɟɟ ɡɧɚɱɟɧɢɟ ɭɫɥɨɜɢɣ, ɤɨɬɨɪɵɟ ɦɨɝɭɬ ɧɚɫɬɭɩɢɬɶ.
Yukarıdaki tablo meydana gelebilecek koúulların ortalama de÷erini göstermektedir.
TC: Total Capacity: kW ; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacity
index
Outdoor
air temp.
(°CDB)
Indoor air temperature: °CB
14.0 16.0 18.0 19.0 20.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130% 1040.0 10 78.1 10.3 93.1 12.6 108 15.0 113 15.5 115 15.2 117 14.6 120 13.9
12 78.1 10.5 93.1 12.8 108 15.2 112 15.4 113 15.1 116 14.5 119 14.2
14 78.1 10.7 93.1 13.1 108 15.5 110 15.4 112 15.0 114 14.9 117 15.0
16 78.1 10.9 93.1 13.3 107 15.6 109 15.5 110 15.6 113 15.7 116 15.9
18 78.1 11.1 93.1 13.6 106 16.2 107 16.3 109 16.4 111 16.5 114 16.7
20 78.1 11.3 93.1 14.5 104 17.0 106 17.1 107 17.2 110 17.3 113 17.5
21 78.1 11.6 93.1 15.0 104 17.4 105 17.5 106 17.6 109 17.7 112 17.9
23 78.1 12.4 93.1 16.1 102 18.2 104 18.3 105 18.4 108 18.5 111 18.7
25 78.1 13.3 93.1 17.2 101 19.0 102 19.1 104 19.2 106 19.4 109 19.5
27 78.1 14.2 93.1 18.4 99.3 19.8 101 19.9 102 20.0 105 20.2 108 20.4
29 78.1 15.2 93.1 19.7 97.8 20.6 99.2 20.7 101 20.8 103 21.0 106 21.2
31 78.1 16.2 93.1 21.0 96.3 21.4 97.7 21.5 99.1 21.6 102 21.8 105 22.1
33 78.1 17.2 92.1 21.9 94.9 22.2 96.3 22.3 97.7 22.4 100 22.7 103 22.9
35 78.1 18.4 90.6 22.7 93.4 23.0 94.8 23.1 96.2 23.2 99.0 23.5 102 23.8
37 78.1 19.5 89.1 23.5 91.9 23.8 93.3 23.9 94.8 24.1 97.6 24.3 100 24.6
39 78.1 20.8 87.7 24.3 90.5 24.6 91.9 24.8 93.3 24.9 96.1 25.2 98.9 25.5
120% 960.0 10 72.1 9.4 86.0 11.5 100 13.6 107 14.7 113 15.6 115 15.0 118 14.4
12 72.1 9.6 86.0 11.7 100 13.9 107 15.0 111 15.5 114 14.9 116 14.3
14 72.1 9.7 86.0 11.9 100 14.2 107 15.3 110 15.4 112 14.8 115 14.9
16 72.1 9.9 86.0 12.1 100 14.4 107 15.6 108 15.5 111 15.6 114 15.7
18 72.1 10.1 86.0 12.4 100 14.9 106 16.2 107 16.3 109 16.4 112 16.5
20 72.1 10.3 86.0 12.9 100 16.0 104 17.0 105 17.0 108 17.2 111 17.4
21 72.1 10.4 86.0 13.3 100 16.6 103 17.4 105 17.4 107 17.6 110 17.8
23 72.1 11.1 86.0 14.3 100 17.8 102 18.2 103 18.2 106 18.4 108 18.6
25 72.1 11.9 86.0 15.3 99.2 18.9 100 19.0 102 19.0 104 19.2 107 19.4
27 72.1 12.7 86.0 16.3 97.7 19.7 99.0 19.7 100 19.8 103 20.0 105 20.2
29 72.1 13.5 86.0 17.4 96.2 20.4 97.5 20.5 98.8 20.6 101 20.8 104 21.0
31 72.1 14.4 86.0 18.6 94.8 21.2 96.1 21.4 97.4 21.5 100 21.7 103 21.9
33 72.1 15.4 86.0 19.9 93.3 22.0 94.6 22.2 95.9 22.3 98.5 22.5 101 22.7
35 72.1 16.3 86.0 21.2 91.8 22.9 93.1 23.0 94.4 23.1 97.0 23.3 99.6 23.6
37 72.1 17.4 86.0 22.6 90.4 23.7 91.7 23.8 93.0 23.9 95.6 24.2 98.2 24.4
39 72.1 18.5 86.0 24.0 88.9 24.5 90.2 24.6 91.5 24.7 94.1 25.0 96.7 25.3
110% 880.0 10 66.1 8.5 78.8 10.4 91.5 12.3 97.9 13.3 104 14.3 113 15.5 116 14.9
12 66.1 8.7 78.8 10.6 91.5 12.6 97.9 13.6 104 14.6 112 15.4 114 14.8
14 66.1 8.8 78.8 10.8 91.5 12.8 97.9 13.8 104 14.9 110 15.3 113 14.8
16 66.1 9.0 78.8 11.0 91.5 13.0 97.9 14.1 104 15.2 109 15.5 111 15.6
18 66.1 9.2 78.8 11.2 91.5 13.3 97.9 14.5 104 15.9 107 16.3 110 16.4
20 66.1 9.3 78.8 11.4 91.5 14.1 97.9 15.6 104 16.9 106 17.1 108 17.2
21 66.1 9.4 78.8 11.8 91.5 14.6 97.9 16.1 103 17.3 105 17.5 108 17.6
23 66.1 9.9 78.8 12.6 91.5 15.6 97.9 17.3 101 18.1 104 18.3 106 18.4
25 66.1 10.5 78.8 13.5 91.5 16.8 97.9 18.5 100 18.9 102 19.1 105 19.2
27 66.1 11.3 78.8 14.4 91.5 17.9 97.3 19.6 98.5 19.7 101 19.9 103 20.1
29 66.1 12.0 78.8 15.4 91.5 19.1 95.9 20.4 97.1 20.5 99.4 20.7 102 20.9
31 66.1 12.8 78.8 16.4 91.5 20.4 94.4 21.2 95.6 21.3 98.0 21.5 100 21.7
33 66.1 13.6 78.8 17.5 91.5 21.8 92.9 22.0 94.1 22.1 96.5 22.3 98.9 22.5
35 66.1 14.5 78.8 18.6 90.3 22.7 91.5 22.8 92.7 22.9 95.1 23.1 97.4 23.4
37 66.1 15.4 78.8 19.8 88.8 23.5 90.0 23.6 91.2 23.7 93.6 24.0 96.0 24.2
39 66.1 16.3 78.8 21.1 87.4 24.3 88.6 24.4 89.7 24.6 92.1 24.8 94.5 25.0
100% 800.0 10 60.1 7.7 71.6 9.3 83.2 11.0 89.0 11.9 94.8 12.8 106 14.7 114 15.4
12 60.1 7.8 71.6 9.5 83.2 11.2 89.0 12.2 94.8 13.1 106 14.9 112 15.3
14 60.1 8.0 71.6 9.7 83.2 11.5 89.0 12.4 94.8 13.3 106 15.2 111 15.3
16 60.1 8.1 71.6 9.8 83.2 11.7 89.0 12.6 94.8 13.6 106 15.5 109 15.5
18 60.1 8.3 71.6 10.0 83.2 11.9 89.0 12.9 94.8 13.9 106 16.2 108 16.3
20 60.1 8.4 71.6 10.2 83.2 12.3 89.0 13.5 94.8 14.8 104 17.0 106 17.1
21 60.1 8.5 71.6 10.3 83.2 12.7 89.0 14.0 94.8 15.4 103 17.4 105 17.5
23 60.1 8.7 71.6 11.0 83.2 13.6 89.0 15.0 94.8 16.5 102 18.2 104 18.3
25 60.1 9.3 71.6 11.8 83.2 14.6 89.0 16.1 94.8 17.7 100 18.9 103 19.1
27 60.1 9.9 71.6 12.6 83.2 15.6 89.0 17.2 94.8 18.9 98.9 19.7 101 19.9
29 60.1 10.6 71.6 13.4 83.2 16.6 89.0 18.4 94.8 20.2 97.5 20.5 99.6 20.7
31 60.1 11.2 71.6 14.3 83.2 17.7 89.0 19.6 93.8 21.2 96.0 21.3 98.2 21.5
33 60.1 11.9 71.6 15.2 83.2 18.9 89.0 20.9 92.4 22.0 94.5 22.2 96.7 22.3
35 60.1 12.7 71.6 16.2 83.2 20.2 89.0 22.3 90.9 22.8 93.1 23.0 95.2 23.2
37 60.1 13.5 71.6 17.2 83.2 21.5 88.3 23.5 89.4 23.6 91.6 23.8 93.8 24.0
39 60.1 14.3 71.6 18.3 83.2 22.9 86.9 24.3 88.0 24.4 90.1 24.6 92.3 24.8
