SiBE041213E Specifications
Specifications 4
1. Specifications
Note:
The data are based on the conditions shown in the table below.
50 Hz, 220 - 230 - 240 V
Model
Indoor Unit FTXS35K2V1B FTXS42K2V1B
Outdoor Unit
RXS35K2V1B RXS42K2V1B
Cooling Heating Cooling Heating
Capacity Rated (Min. ~ Max.)
kW 3.50 (1.4 ~ 4.0) 4.00 (1.4 ~ 5.2) 4.20 (1.7 ~ 5.0) 5.40 (1.7 ~ 6.0)
Btu/h 11,900 (4,800 ~ 13,600) 13,600 (4,800 ~ 17,700) 14,300 (5,800 ~ 17,100) 18,400 (5,800 ~ 20,500)
kcal/h 3,010 (1,200 ~ 3,440) 3,440 (1,200 ~ 4,470) 3,610 (1,460 ~ 4,300) 4,640 (1,460 ~ 5,160)
Moisture Removal L/h 1.9 — 2.3 —
Running Current (Rated) A 4.3 - 4.1 - 3.9 4.3 - 4.1 - 3.9 6.0 - 5.7 - 5.5 6.6 - 6.3 - 6.0
Power Consumption
Rated (Min. ~ Max.)
W 840 (350 ~ 1,190) 840 (340 ~ 1,460) 1,180 (320 ~ 2,330) 1,310 (400 ~ 1,980)
Power Factor % 88.8 - 89.1 - 89.7 88.8 - 89.1 - 89.7 89.4 - 90.0 - 89.4 90.2 - 90.4 - 91.0
COP (Rated) (Min. ~ Max.) W/W 4.17 (4.00 ~ 3.36) 4.76 (4.12 ~ 3.56) 3.56 (5.31 ~ 2.15) 4.12 (4.25 ~ 3.03)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ 18.0 φ 18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FTXS35K2V1B FTXS42K2V1B
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
11.2 (395) 12.1 (427) 11.2 (395) 12.4 (438)
M
8.5 (300) 9.3 (328) 9.1 (321) 10.0 (353)
L
5.8 (205) 6.5 (230) 7.0 (247) 7.8 (275)
SL
4.1 (145) 4.2 (148) 4.1 (145) 5.2 (184)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.13 - 0.13 - 0.12 0.11 - 0.11 - 0.11 0.14 - 0.14 - 0.13
Power Consumption (Rated) W 26 - 26 - 26 28 - 28 - 28 24 - 24 - 24 30 - 30 - 30
Power Factor % 98.5 - 94.2 - 98.5 97.9 - 93.6 - 97.2 99.2 - 94.9 - 90.9 97.4 - 93.2 - 96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 298 × 900 × 215 298 × 900 × 215
Packaged Dimensions (H × W × D) mm 290 × 977 × 371 290 × 977 × 371
Weight (Mass) kg 11 11
Gross Weight (Gross Mass) kg 15 15
Sound Pressure Level (H / M / L / SL) dB(A) 45 / 37 / 29 / 19 45 / 39 / 29 / 19 45 / 39 / 33 / 21 45 / 39 / 33 / 22
Sound Power Level dB 59 59 59 59
Outdoor Unit RXS35K2V1B RXS42K2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 2YC36BXD
Motor Output W 600 1,100
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.650
Refrigerant
Type R-410A R-410A
Charge kg 1.2 1.3
Airflow Rate
H
m³/min
(cfm)
36.0 (1,271) 28.3 (999) 37.3 (1,317) 31.3 (1,105)
SL 30.1 (1,063) 25.6 (904) 30.6 (1,080) 27.2 (960)
Fan
Type Propeller Propeller
Motor Output W 23 50
Running Current (Rated) A 4.18 - 3.98 - 3.79 4.17 - 3.97 - 3.78 5.89 - 5.59 - 5.39 6.46 - 6.16 - 5.87
Power Consumption (Rated) W 814 - 814 - 814 812- 812 - 812 1,156 - 1,156 - 1,156 1,280 - 1,280 - 1,280
Power Factor % 88.5 - 88.9 - 89.5 88.5 - 88.9 - 89.5 89.2 - 89.9 - 89.4 90.1 - 90.3 - 90.9
Starting Current A 4.3 6.6
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 612 × 906 × 364 612 × 906 × 364
Weight (Mass) kg 34 39
Gross Weight (Gross Mass) kg 38 45
Sound Pressure Level (H / SL) dB(A) 48 / 44 48 / 45 48 / 44 48 / 45
Sound Power Level (H) dB 63 63 63 63
Drawing No. 3D080619 3D080620
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
